Specifications
It is durable,economical and practical for trainees to study PLC and hydraulic knowledge and do practical operations.| XK-YY2 Hydraulic Transmission Teaching Training Device |
1. Product structure:
Desktop structure working mesa used the "T" type aluminum materials, provides great convenience for the installation and location of hydraulic element...
2. Main parameters:
Size :1500 mm x 750 mm x 1800 mm;
The power supply: the three-phase AC380V, power < 500 VA.
3. Main components:
The training platform, aluminum working mesa, the power modules, PLC module, relay module, hydraulic components (including double role oil cylinder (with stroke collision block), spring return oil cylinder, hydraulic controlled one-way valve, pressure reducing valves, auxiliary oil tank, and pressure relay, pressure oil cylinder, throttle valve (direct-acting style), one-way valve, order valve, hydraulic special using pump station, tools accessories components.
4. Main functions:
PLC commonly used programming instructions learning and training, hydraulic loop machine learning basic training. Have a safety protection function.
5. Annex:
Experimental jump line, commonly used tools, software disc, the product specification.
6. Training project:
The hydraulic circuit of pilot projects:
1)the electromagnetic valve commutation loop;
2)O-function, M-function valve latch circuit;
3)pilot-operated check valve atresia;
4)the pressure it is set loop;
5)two pressure control loop;
6)valve decompression circuit;
7)H-type electromagnetic valve unloaded loop;
8)into the oil throttle speed control loop;
9)circuit throttle speed control loop;
10)the throttle valve in parallel with throttle speed control loop;
11)the order of action of the sequence valve circuit;
12)the order of action of the pressure relay loop;
13)circuit limit switch the order of action;
14)the order of the trip valve action loop;
The programmable logic controller (PLC) electrical control experiments;
1)PLC's programming instructions, ladder programming learning;
2)PLC programming software to learn and use;
3)PLC control solenoid valve commutation circuit...
XINGKE Products Specifications:
The First-Class Vocational Teaching Equipment Supplier/Manufacturer in People’s Republic of China.
1. Good quality
Reasonable design and original layout, be suitable for teaching and training.
2. Reasonable price
3. OEM Service
