Specifications
It is durable,economical and practical for trainees to study PLC and pneumatic knowledge and do practical operations| XK-QD2 PLC control Pneumatic Teaching Training Device |
1. Product structure:
Desktop structure ,working mesa used the "T" type aluminum materials, provides great convenience for the installation and location of pneumatic components.
2. Main parameters:
Size:1500 mm x 750 mm x 1800 mm;
The power supply: the three-phase AC380V, power < 500 VA.
3. Main components:
The training platform, aluminum working mesa, the power module, PLC module, relay modules, pneumatic components (including air filtration, reduced pressure, oil mist is a joint, pressure reducing valve, the manual directional control valves, electromagnetic reversing valves, air control directional valves, travel valves, one-way valvesthrottle valve, one-way throttle valve, quick exhaust valve, the single-acting cylinder, double-acting cylinder), gas source, and tool accessories components.
4. Main functions:
PLC commonly used programming instructions learning and training, pneumatic basic loop training. Have a safety protection function.
5. Annex:
Experimental jump line, commonly used tools, software disc, the product specification.
6.Training project:
1 Single-acting cylinder reversing loop
2 Double-acting cylinder reversing loop
3 Single-acting cylinder speed control loop
4 Double-acting cylinder on-way speed regulation loop
5 Double-acting cylinder both way speed regulation loop
6 Speed changing-over loop
7 Buffering loop
8 Twice pressure control loop
9 Counting loop
10 Delay loop
11 Overload protection loop
12 Interlocking loop
13 Single cylinder single reciprocating control loop
14 Single cylinder continuous reciprocating action loop
15 Double-cylinder sequential action loop
16 Double-cylinder synchronization action loop
17 Unloading loop
18 Joint gate type shuttle valve application loop
19 Rapid escape valve application loop...
The advantage of our Product:
XINGKE Products Specifications:
The First-Class Vocational Teaching Equipment Supplier/Manufacturer in People’s Republic of China.
1. Good quality
Reasonable design and original layout, be suitable for teaching and training.
2. Reasonable price
3. OEM Service
