Specifications
1.educational training equipment2.XK-PC6140A ordinary lathe
vocational training equipment, XK-PC6140A ordinary lathe
An overview,
This series lathe wide range of USES, mainly used for all kinds of outer circle of axially symmetrical parts, inner hole, end face, taper, grooving, and metric thread, the modulus of thread, diametral pitch thread turning processing, also can be used for drilling, reaming, tapping, knurled processing, etc. Suitable for the use of carbide cutting tools for super high speed cutting various metal and non-ferrous metal. High machining precision, easy manipulation, modelling beautiful generous. According to the center distance with different machine tool lathe bed length 750 mm, 750 mm, 1500 mm, and other three kinds of specifications, user according to the specific usage of choice.
Second, the characteristics of
1, lathe bed guide rail with adding boron high strength meehanite cast iron, super audio quenching and fine grinding.
2, high spindle speed, spindle hole diameter is big.
3, the main shaft spline using large diameter centering, centering precision is high.
4, electrical system conforms to the IEC standard.
5, the transmission system metric/inch.
6, the spindle head C/D.
7, all kinds of voltage and frequency of the electrical system.
Third, the main technical parameters
Car bed type no. |
C6140A |
|
Maximum turning diameter of bed |
400mm |
|
Saddle groove maximum turning diameter |
580mm |
|
Rest on the maximum turning diameter |
240mm |
|
From the top |
750mm 1000mm 1500mm |
|
The spindle hole diameter |
50mm |
|
The spindle head type |
ISO 702/ⅡNO.6/ISO 702/ⅢNO.6 |
|
Spindle speed |
30-1600r/min(12) |
|
The main electric power |
4/4.5kw |
|
The tailstock sleeve diameter |
60mm |
|
|
Packing size
|
750 mm |
2100×1080×1600mm |
1000 mm |
2300×1080×1600mm |
|
1500 mm |
2800×1080×1600mm |
|
Machine tool gross weight |
750 mm |
1350kg |
1000 mm |
1380kg |
|
1500 mm |
1400kg |
|
