Specifications
1, Experiment box structure, easy to carry2, Can finish based on FPGA related interface experiment and the expand experiment.
| XK-FPGA1 High Performance EDA Training Kit |
1. Product structure:
The experiment box structure, easy to carry.
2. Main parameter :
Size: 500mm x 340mm x 165 mm;
Power supply: single-phase AC 220V±5% 50Hz ≤45VA.
3. Main composition:
EDA son board, keyboard module, storage module, modulus analog-to-digital conversion module, the I2C interface chip, liquid crystal display module interface, RS232 interface, double color dot matrix modules, digital display module, multi-function pulse source, experimental connecting cables, audio power amplifier circuit, VGA display interface, the power modules, a buzzer, LED display module, electricity level switch module, USB interface module, and fixed frequency resource module...
4. Main functions: can finish based on FPGA related interface experiment and the expand experiment.
5. Annex:
JTAG download cable, experiment jump line, commonly used tools, software disc, the product specification.
6. Training project:
1) four people adding machines
2) prescaler
3) trigger
4) add and subtract counter
5) digital stopwatch
6) LED control experiment
7) a buzzer control experiment
8) csaladfai, static shows the experiment
9) csaladfai, dynamic scanning experiments
10) key recognition experiment
11) EEPEOM experiment
12) liquid crystal display experiment
13) VGA display experiment
14) and serial interface communication experiment
15) PS2 keyboard experiment
16) DS1302 experiment
17) DS18B20 experiment
18) SD card experiment
19) infrared experiment
20) AD experiment
21) DA experiment
22) motor drive experiment
23) network communication experiment
24) a digital clock
25) the frequency meter
26) light
27) vies to answer first device.
1. The advantage of our Product:
XINGKE Products Specifications:
The First-Class Vocational Teaching Equipment Supplier/Manufacturer in People’s Republic of China.
1. Good quality
2. Reasonable design and original layout, be suitable for teaching and training.
2. Reasonable price
3. OEM Service
