It is durable,economical and practical for trainees to study the principle of car stepping motor and do operational equipment. Electrical Trainer Stepping Motor Experimental Box
1. Product Overview:
Stepper motor test box by DC12V four-phase stepper motor, PIC microcontroller control unit PLC control interface unit, the control button, indicator, and other components. Suitable for students at PLC, microcontroller programming control training, and stepper motor control training. Communication with the PC through the USB port...
2. Main parameters:
1,Supply voltage: AC220V, 50Hz;
2, Current: ≤ 1A;
3, Size: 370mm * 220mm * 120mm (L * W * H);
4, Weight: 5KG;
5, The stepper motor;
5.1 Model: 25BY48;
5.2 Rated voltage: DC12V;
5.3 Number of phases: 4;
5.4 each step of the corner: 3.75;
5.5 pulses per revolution: 96;
5.6-phase current: 0.3A;
6, single-chip models: PIC16F628A;
3. Main function:
1 learning the work of the four-phase stepper motor and control methods.
2 learn how to use microcontroller to control the four-phase stepper motor.
3 learn how to use the PLC to control the four-phase stepper motor.
4 learning to use the PC + single-chip control of the four-phase stepper motor...
