Specifications
1.electrical lab equipment, training kit, electrical technology train2.electric and electronic lab device
3.ISO,CE, OEM
| XK-SX5A Electrical Wiring and Assembly Technology Training Device (double station) |
Latest Electrical Technology, Electrical Lab Equipment, Electrical Wiring and Assembly Training Kit
1. System overview:
XK-SX5A electrical wiring and assembly technology training device consists of training table and mesh board. The training platform offers AC power, DC power. The power part has short circuit, over current and leakage protection and so it is safe and reliable...
Structure:
The training table body is a steel plate structure and sprayed, its table top is a high density plate which is fire prevention, waterproof and wearproof. It suitable for double persons to sit, provides two electrician training mesh boards, two sets of reference power supply and two person can do practice training at the same time.
Training platform can be determined by oneself ,can select the corresponding components according to actual training project and so it is easy to expand.
2. Technical specifications:
2.1.Power part:
1.Input voltage:AC380V±10%,50Hz,three-phase four-wire;
2.Three-phase main power switch equipped with leakage protection;
3.Three-phase,single-phase output equipped with automatic air switch, volume 10A;
4.Accident emergency button, power indication, power supply indication;
5.Mains socket.
2.2.signal source:
2.1.+24V DC voltage source equipped with switch and short-circuit protection;
2.24V AC voltage source equipped with switch and short-circuit protection;
2.3.Product oversize: 1530 mm×700 mm×1700mm...
3. Experiment content:
1.Direct starting control of three-phase asynchronous motor
2.Inching control circuit of three-phase asynchronous motor contactor
3.Self-locking control circuit of three-phase asynchronous motor contactor
4.Inching and self-locking control circuit of three-phase asynchronous motor
5.Positive and negative rotation control circuit of button interlocking control motor
6.Positive and negative rotation control circuit of contactor interlocking control motor
7.Positive and negative rotation control of dual-interlocking button contactor
8.Manual sequence control of three-phase asynchronous motor
9.Auto-sequence control of three-phase asynchronous motor
10.Multi-sets control of three-phase asynchronous motor.
Total up 20 different contents...
