| XK-SX1A Primary Maintenance Electrician Training and Evaluation Device |
1. Product structure:
Cabinet double-sided structure, the experiment equipment be clear at a glance, and students do the wiring, and realistic strong, easy to organize various training programs...
2. Main parameters:
Size: 800 mm x 540 mm x 1700 mm;
The power supply: the three-phase AC380V, power < 2000 VA.
3. Main components:
The training cabinet, power supply control panel and training panel, motor control training unit, instrument lighting training unit etc.
4. Main functions:
Set training, theory test, the actual operation ability, examination, use double-sided space of cabinet , decorate appliances and supporting matched experiment equipment, can finish primary electrician electric drive control and lighting circuit real training program, link theory with practice, outstanding skills training, pay attention to pertinence, practical and scientific.
5. Annex:
Experimental jump line, commonly used tools, the product specification.
6. Training Projects:
Three-phase motor control
6.1. Direct starting asynchronous motor circuit.
6.2. Asynchronous motor point start control circuit.
6.3. Asynchronous motor self-locking control circuit.
6.4. The two asynchronous motor (more) control circuit.
6.5. Y-train start automatic control circuit.
6.6. With the fall of switch of the three-phase asynchronous motor control and reversing.
6.7. Asynchronous motor contactor interlocking positive &negative control circuit
6.8. Asynchronous motor button interlocking positive &negative control circuit
6.9. Automatic sequence starting control.
6.10. Manual starting control order.
Total up to 21 experiments...
* Instrument and lighting experiment, practice projects:
Incandescent lamp control circuit.
Fluorescent lamp control circuit
Touch switchcontrol incandescent lamp circuit
Voice control switch control stair incandescent lamp circuit.
Infrared switch control stair incandescent lamp circuit.
Single phasewatt-hour meter installed directly circuit.
Single phasewatt-hour meter indirect installation circuit.
Three-phase watt-hour meter installed directly circuit.
Three-phase watt-hour meter indirect installation circuit.
Voltmeter and ammeter installation circuit.
Current transformer and ammeter with connection circuit.
A current transformer used in single-phase circuit connection circuit.
Three table current transformer joint into star line connection circuit.
Three table current transformer joint into triangle connection circuit.
Two sets of current transformer differential connection circuit.
Universal switch and voltmeter measurement three-phase voltage wiring circuit.
