Delicate PVC Ceiling Panel Mould
Name |
Delicate PVC Ceiling Panel Mould |
Size |
Various types |
Mould material |
3Cr17, 3Cr17MoNiV,or as per your request |
Mould cavity |
1 or multi-cavity |
Mould composition |
Die head, aluminum heating bands, calibrators and water tank |
Feature |
Selectable co-extrusion of different raw materials: PVC, PP, PE, ABS Selectable technology: low-foaming, high-foaming & substance co-extrusion Stable discharging, high efficiency, superior quality |
Test |
Mould will be tested to get the satisfied sample before delivery |
Service |
Provide complete set of production process and technology transfer service |
Lead time |
30 days |
Package |
Wooden case for exporting, each mould will be cleaned before packaging. |
Hubei TianRui Delicate PVC Ceiling Panel Mould Characters:
The extrsion die head design:
Use the removable positioning device,making it easier to disassemble.
Precise material flowing control and stable extrusion.
The hidden heating design has increased the brightness of the product surface.
The special balance of the pressure holes has lowered the rejection rate.
The extrusion calibrator design:
The autnmatically adjusting positioning key gives it a precise size
The tapered design of the calibration sleeve has increased the production speed greatly.
The inlet end is independent vaccum and shapes well.
The camber ajusting device ensures that the line is straight.
Extrusion cooling design:
Double vaccum system promotes the molding.
The combination design of eddy current and spray makes it easier to adjust
The stainless steel frame type systam can prevent damage
The special influent distribution gives it a cooling balance
Hubei TianRui Plastic has set up an indepent R & D center and we have successfully developed a series of high-speed extrusion mould,soft and hard strip co-extrusion mould,multi-material fully coated co-extrusion mould,surface forming mould,foaming mould,WPC mould,wide plate mould and decorative profile mould.Our products have won the praise of our customers both home and abroad.We will guarantee the rapid technological upgrading to meet customers’unique and diverse needs.
If you need any further information, please be free to contact me, we will be very happy to receive your kind message.
Sindy
Hubei TianRui Plastic Mould Co.,Ltd
Tel: 86-0714-3089139
Fax: 86-0714-3089399
MSN: Chenmo123@
Skype:tr1369999
QQ:921653668
