SSC-TJ-027(XK) Training Bench of AC Charging PileNegotiableMOQ: 1 -
SSC-TJ-026(XK) Training Bench of High Speed Electric Automobile Power SystemNegotiableMOQ: 1
-
SSC-PJ-005(XK) Electric Motor Dissection ShowcaseNegotiableMOQ: 1
-
SSC-PJ-001(XK) Battery Dissection Display CabinetNegotiableMOQ: 1
-
SSC-TJ-025(XK)Training Bench of Low Speed Electric Auto's Power SystemNegotiableMOQ: 1
SSC-TJ-028(XK) Experiment Bench of Power Conversion System is the equipment of new energy auto battery training room. As a theory-practice integrated training equipment, it demonstrates the principle of power conversion comprehensively and realizes that DC converts to motor required three – phase AC, and power battery DC converts to motor required electrical motor DC, and AC converts DC.
1. Power supplies：AC 220V ±10% 50Hz
2. Current supplies: ≤32A
3. Adopting 4mm aluminum composite panel with color printed pad pasting treatment, the measurement panel is painted with colorful actual object diagram and schematic diagram of sensors, actuators, and arrangement diagram of connector pin.
4. The detecting terminal is directly installed on the schematic diagram, so it could help students understand the principles of transformation based on the corresponding principle.
5. Temperature：－10℃—40℃
6. Relative humidity：≤85﹪ （25℃） height：＜4000m
7. Security：There are leakage voltage protection and leakage current protection devices which are in accordance with national standards.
1. The training of DC/DC boost module system circuit principle
2. The training of DC/DC step-down module circuit principle
3. The training of AC/DC module system circuit principle
4. The training of battery module system of DC/AC module circuit principle
5. The training of faults setting and shooting ideas and methods
