Diesel Welder Generator Set

Name: Diesel Welder Generator Set
Brand: BOBIG
SKU: 109131035
Availability: InStock

Negotiable MOQ: 10 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

BOBIG

Model Number:

BD190WLE

Fujian Bobig Electric Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FUZHOU

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name BOBIG

Model Number BD190WLE

Output Type AC Single Phase

Speed 3000RPM/3600RPM

Frequency 50HZ/60HZ

Rated Power 4.0KW

Rated Voltage 110,120,220,230,240,110/220

Specifications

diesel welder generator set
double function with welder&generating
good performance
easy for transprotation
CE,ISO9001

DIESEL WELDER GENERATOR SET

190A copper winding,new italian power generator,welding technology.

Rated frequency (Hz)	50 60
Rated power(kW)	5.0 5.5
Rated voltage (V)	230 240/120
Rated current (A)	21.7 23/45.8
No.of phase	Single
Power factor (cosφ)	1
Weldling voltage at zero load (DC)(V)	60-70
Rated weldling current DC(A)	180
weldling voltage(DC)(V)	25-30
Weldling load continous ratio	60%
Weldlig current adjustment range(A)	50-190
Electrode φ(mm)	1.6-4.0
Rated speed (r/min)	3000 3600
Excitation mode	Self-excitation and constant voltage (AVR)
Recifying mode	IGBT+three-phase rectifying bridge (PWM)
Insulation grade	F
Pole number	2
Engine Model	BD186
Engine type	Single-cyinder,four-stroke,OHV,air-cooled
Cylinder NO,-bore×stroke(mm)	1-88×64
Displacement	389
Rated power[kW(Hp)/(r/min)]	10.0/300011/3600
Compression ratio	8.5:1
Rated rotation speed	3000 3600
lgnition system	T.C.I
Cooling system	Air cooled
Lubrication system	Splash
Starting system	X:Recoil starter E:Electric starter
Fuel type	Automotive unleaded gasoline
Lube oil Brand	CDgrade or SAE10W-30,15W-40
Capacity of cooling Water(L)	Without
Lube capacity (L)	1.1
Starting motor capacity (V-kW)	12V 0.4kW
