OEM Kubota Water-cooled Generator Set 12kw
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
BOBIG/OEM, BOBIG
Model Number:
BK17S/BK17
Payment & Shipping
Payment Methods:
Port of Shipment:
FUZHOU
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Yammar Diesel Engines Generating Set 8KWUS$ 2,500 - 500,000MOQ: 1 Set -
Deutz Brushless Excitation Diesel Generator Set 36KWUS$ 4,000 - 100,000MOQ: 1 Set
-
EPA Diesel Generator 20KW-536KW for SaleUS$ 2,500 - 500,000MOQ: 1 Set
-
Deutz Stamford Alternator Technology Diesel GeneratorNegotiableMOQ: 1 Set
-
Yangdong A.V.R Diesel Generators 8kw-30kwUS$ 1,000 - 500,000MOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
BOBIG/OEM, BOBIG
Model Number
BK17S/BK17
Output Type
AC Three Phase
Speed
1500rmp/1800rpm
Frequency
50/60Hz
Rated Power
12KW/15KVA
Rated Voltage
220,230,110/220 It up to your optional
Rated Current
21.6A
Specifications
OEM KUBOTA generator set1.mous engine with stamford/Leroy somer alternator
2.tional ATS or AMF
3.one year warranty
OEM KUBOTA Water-cooled generator set 12kw
| KUBOTA series diesel generator(3phase) | |||
| Specification data | |||
| Genset model | BK17S | ||
| Prime Power of genset | 12KW/15KVA | ||
| Standby Power | 13.2/17 | ||
| KUBOTA ENGINE | Model | D1703-BG | |
| Type | Vertical 4 cycle liquid cooled Diesel | ||
| No.of Cylinders | 3 | ||
| Bore*Stroke mm(in) | 87.0*92.4(3.43*3.64) | ||
| Displacement | 1.647(100.51) | ||
| Combustion System | E-TVCS | ||
| Intake System | Natural aspirated | ||
| Fuel Injection Pump | Bosch type PFR MD pump | ||
| Direction of Rotation | Counterclockwise(viewed from flywheel side) | ||
| Injection Nozzle | Throttle type | ||
| Compression Ratio | 23 | ||
| Lubricating Oil | Quality better than CD class | ||
| Oil Pan Capacity L(gal) | 7.0((1.85) | ||
| Cooling System | Radiator cooling | ||
| Starter Capacity V-A | 12-1.2 | ||
| Alternator Capacity V-A | 12-40 | ||
| Used Fuel | Diesel Fuel No.2-D(ASTM D975) | ||
| Dry Weight kg(lbs) | 148.0(326.3) | ||
| Leroy Somer Alternator | Alternator Model | LSA 40 VS3 | |
| Alternator manufacturer | Leroy Somer | ||
| Exciter type | Single bearing ,Brushless,Self-excited | ||
| Prime power | 12kw/15KVA | ||
| Rated speed | 1500RPM | ||
| Rated frequency | 50Hz | ||
| Phase | 3 | ||
| Rated Voltage | 400V/230V(Available with customer requirements) | ||
| Power factor | 0.8 | ||
| Voltage adjust range | 5% | ||
| Voltage regulation NL-FL | +-1% | ||
| Insulation grade | H | ||
| Protection grade | IP23 | ||
