Gensets

Gensets thumbnail-1
Gensets photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
BOBIG or OEM
Model Number:
GF
Contact Supplier Request Quote Chat Now
Fujian Bobig Electric Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
FUZHOU
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name BOBIG or OEM
Model Number GF
Output Type AC Three Phase
Speed 1500/1800r.m.p
Frequency 50hz/60hz
Rated Power 8kw-536kw
Rated Voltage 220v,480/208v

Specifications

Gensets
Genset with Brushless alternator
Economical performance
Long-Life Durability
CE,ISO9001

Gensets



General Data
Genset Power 20KW/25KVA 30KW/37.5KVA 1000KW/1250KVA
Perkins engine Engine model   1103A-33G 1103A-33TG1 4012-46TAG2A
Engine power   24KW/30KVA 36KW/45KVA 1267KW/1584KVA
Number of cylinders   3Vertical in-line 12 60°Vee form
Bore and Stroke   105*127mm 160*190mm
Displacement   3.3Litres 45.842litres
Aspiration Naturally aspirated Turbocharged Turbocharged and air to air charge cooled
Cycle 4 Stroke
Combustion system   Direct injection
Compression ratio   19.25:1 17.25:1 13.6:1
Rotation    Anti-clockwise,Vewed from flywheel
Cooling system   Water-cooled
Total lubrication system   7.9litres 177litres
Total coolant capacity   10.2litres 207litres
Alternator Cooling starting Method   Closed water cooled/Electric start
Model PI 142D PI 142G LVI 634G
Rated output(kw)   20KW/25KVA 30kw/37.5KVA 1000KW/1250KVA
Rated voltage(V)   380,400,415/200 according to your special request
Frequency(HZ)   50HZ
Power Factor    0.8Lagging
Phase/Connection   3-phase 4-wire Y type connection
Excitation   Brushless Excitation
Voltage Regulation   A.V.R

We will try my best to supply the product according to your specific requirement.
