Help CenterJAC Refueling Tank Truck ,5ton Refueling Truck
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Storage:
Oil
Drive Wheel:
4x2
Payment & Shipping
Payment Methods:
Port of Shipment:
any port in china
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
JAC Fuel Tank Truck ,refueler Tank TuckNegotiableMOQ: 1 Unit -
Yuejin Fuel Truck With Dispenser ,refueling Tank TruckNegotiableMOQ: 1 Unit
-
Refuel Tank Truck ,8 Ton Refuller TruckNegotiableMOQ: 1 Unit
-
Rigid Fuel Truck ,fuel Truck With Pump and DispenserNegotiableMOQ: 1 Unit
-
China Factory 15000L Fuel Dispenser Truck on SaleNegotiableMOQ: 1 Unit
Condition
New
Storage
Oil
Drive Wheel
4x2
Horsepower
Other, < 150hp
Transmission Type
Manual
Fuel Type
Diesel
Engine Capacity
EURO 2 OR EURO 3 OR 4
Dimensions (L x W x H) (mm)
5990*1860*2300mm
Brand Name
CHENGLIWEI
Place of Origin
Hubei, China
Model Number
CLW
Gross Vehicle Weight
4490
Specifications
JAC refueling tank truck ,5ton refueling trucktruck with pump and dispenser
good quality
JAC refueling tank truck ,5ton refueling truck
Product Description
| Product Technical Specifications | ||||
| Item | Descriptions | Spesifications and Types | ||
| Vehicle | Brand | CHENGLIWEI | ||
| Overall Dimensions L*W*H | 5990*1860*2300mm | |||
| Weights | GVW. | 4490kgs | ||
| Kurb Weight | 2860kgs | |||
| Rated Payload | 1500kgs | |||
| Chassis | Chassis Brand | JAC | ||
| Drive Type | 4×2 | |||
| Steering | Left hand drive or right hand drive | |||
| Engine | Brand | Yuchai engine | ||
| Power | 85Kw /115HP | |||
| Emmission Level | Euro 2 or euro 3 or euro 4 | |||
| Performance | Max. Speed | 95km/h | ||
| Wheel base | 3308 mm | |||
| Tyre Specifications | 6.50-16 8PR,6.50R16 8PR,7.00-16 8PR, | |||
| No. of Tyre | 6pcs (1 spare tyre included) | |||
| Cab | Cab Capacity | 2 persons allowed | ||
| Body/Superstructure | Tank | Capacity | 3-6m³ | |
| Material | 5mm or 6mm high quality carbon steel | |||
| Loading System | Top filling from manhole or pump fuel into tank from oil inlet valve. | |||
| Discharging System | Pump fuel out from tank or gravity discharge. | |||
| Basic Equipments |
Install fuel pump drive by truck engine through PTO; One manhole, two pcs of fuel hoses (3inches) with complete quick connectors, access ladder, tank top anti-slip steel mesh installed, anti-static device, one fire extinguisher, with two corners’ lights and reflective tape. | |||
| Paint | Tank color is according to client’s requirements. |
|||
| Optional Equipments | Air Conditioner | |||
| Bottom loading | ||||
| Flow meter, rolling hose with nozzle, emergency valve, compartment number, epoxy coating inside tank and so on. | ||||
Detailed Images
