Diesel Engine Generator Set

Name: Diesel Engine Generator Set
Brand: Bobig(Quanchai engine)
SKU: 109125085
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

Bobig(Quanchai engine)

Model Number:

GF8-GF30

Fujian Bobig Electric Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Fuzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name Bobig(Quanchai engine)

Model Number GF8-GF30

Output Type AC Three Phase

Speed 1500r.m.p/1800r.m.p

Frequency 50hz/60hz

Rated Power 8kw-536kw

Rated Voltage 220v,480/208v it up to your choice

Specifications

diesel engine generator set
Quanchai engine(famous in china)
Automatic Protection
CE,ISO9002
High cost performance

diesel engine generator set

THE BRAND OF ENGINE:QUCHAI ENGINE(FAMOUS IN CHINA)

Stable Fuction

Main specification
Genset Model		GF-8	GF-10	GF-12	GF-15	GF-20	GF-24	GF-30
ENGINE	Engine model	QC380	QC385	QC480	N485	QC490	QC4102	QC4102
	Engine type	3 cylinders, direct inline		4 Cylinders, direct in line, Four strokes
	Combustion type	Direct injection			Vortex	Direct injection
	Bore*Stroke (mm×mm)	80×90	85×9	80×90	85×95	90×100	102×105	102×105
	Rated power	22	22	29	34.5	37	63	63
	Rated Fuel comsuptiong/kW.h	249.5	249.5	≤249.5	≤282.9	≤265.2	≤238	≤238
	Oil comsuption	≤0.8	≤0.8	≤0.8	≤2.72	≤2.72	≤0.8	≤0.8
	Max torque/speed(N.m/r/min)	78.4/2100	78.4/2100	104.8/2100	123/2100	147/1980	204/2310	204/2310
	Cooling method	Forced water cooled
	Lubricating way	pressure & splash lubrication
	Starting method	Electric starting
ALTERNTOR	Model	164B	164C	164D	184E	184F	184G	184H
	Rated Output(KW)(KVA)	8(10)	10(12.5)	12(15)	15(18.8)	20(25)	24(30)	30(37.5)
	Rated Voltage(V)	400/230V
	Frequency(HZ)	50/60
	Power Factor	0.8 lagging
	Phase/Connection	3-phase 4-wire Y-type connection
	Excitation	Harmonic or Brushless Excitation
	Voltage Regulation	Manual/Automatic
