The AS10 series high-energy arc spray coating equipment is of an advanced standard, and characterized by excellent performance, reliable quality, easy operation and reasonable price.
The AS10 pull&push-type arc spray coating equipment consists of:
1. Model AS10-LA pull-type arc pistol
2. Model AS10-D power supply unit for arc spray coating
3. Model AS-10-F wire feeder
The arc spray-coating machine is mainly used to prevent against large area corrosion and deal with large area abrasion of steel structures, repair surfaces of mismachined machine parts and prepare the conductive coating of capacitors.
Main coating materials: zinc, aluminum, terne alloy, copper, carbon steel and stainless steel.
This arc pistol can be attached to machine tools for spray coating large work pieces of regular shapes as required by production processes of different operating conditions.
III. Main Specifications and Features
Specifications and features of AS10-TLA pull-type arc pistol Arc spray system for wire coating
Item |
Description |
Basic parameter |
|
1 |
Input powder supply |
Three-phase AC400V, 50Hz |
|
2 |
Rated input powder |
18.8KVA |
|
3 |
Max current |
400A |
|
4 |
No-load output voltage |
DC 21~45V |
|
5 |
Load factor |
60% |
|
6 |
Voltage regulating stages |
3stages each for coarse and fine adjustments, a total of 9 stages |
|
7 |
Overall dimension of power supply unit |
600×460×850mm |
|
8 |
Weight of power supply unit |
220Kg |
|
9 |
Overall dimension of wire feeding device |
465×360×330mm |
|
10 |
Weight of wire feeding device |
20Kg |
|
|
Motor of wire feeding device |
DC24V 3.2A |
|
11 |
Weight of gun |
3Kg |
|
12 |
Air pressure |
≥0.6Mpa |
|
13 |
Wire size |
φ3.2mm |
|
14 |
Insulation level |
B |
|
15 |
Spraying efficiency |
φ3.2mm zinc wire |
≥30Kg/h |
φ3.2mm aluminum wire |
≥12.5Kg/h |
||
1. It is suitable for the pull-type arc pistol; however it can also be used in case of the push-type arc pistol.
2. This power supply unit integrates the arc pistol operating condition control, wire feeding speed control and air piping, and therefore it is ideal special equipment for arc spray coating.
3. It is easy to control and operate. Synchronous control with the switch of the power supply unit at a distant end can be realized just by turning the switch on the arc pistol.
