GASI045 ASI to E3/DS3 Converter
GASI045 is a high performance ASI to E3/DS3 adapter, converting 4 ASI inputs to 1 E3/DS3 and 1 E3/DS3 Input to 4 ASI outputs. GASI045 offers a cost effective bridge between digital TV Headend MPEG-II TS and SONET/SDH Network.
Features
l 19” 1RU chassis and front panel parameter selection
l E3/DS3 Complied with ITU-T G.703
l Supporting Framing in accordance with G.832/G.751 (E3) or G804/G.752 (DS3)
l Supporting prevailing Digital TV Headend protocols
l Bi-Directional conversion between MPEG-II TS and E3/DS3
l 4 channels ASI TS simple mux and demux
l Built-in Clock Recovery
l Supports FEC, RS
l ASI TS Spread/Burst mode Auto Negotiation
l PCR correction and bit stuffing
l Static PID filtering
Specifications
ASI Number of inputs/outputs: 4
ASI Connector: BNC ASI Impedance: 75 Ω
ASI Packet format: 188 or 204 byte packets
E3/DS3 Rx /Tx Connector: BNC E3/DS3 Impedance: 75 Ω
E3/DS3 Format: unframed or framed
E3/DS3 Interface type: E3 (34.368Mbit/s) or DS3 (44.736Mbit/s) in accordance with G.703
Control
Front panel and keypad: system configuration and alarm display
SNMP remote control
Physical
Dimensions: 483 ×350 ×44 (mm)
Weight: 6Kg
Power Supply: 100~240V AC 50/60Hz
Power Consumption: 11.0W Maximum
Environmental
Operating temperature: 0ºC to 45ºC
Relative humidity: 10~90% (Non-condensing)
Ordering Information:
GASI045 MPEG-II ASI to E3/DS3 Converter
