GONU1000W ONU with Wi-Fi
GONU1000W is a cost-effective GEPON customer premise device designed for indoor residential and Single Office/Home Office (SOHO) installation. It supplies Gigabit broadband service to a connected subscriber’s gateway or computers. GONU1000 provides four 10/100M Base-T Ethernet ports with Wi-Fi for Data and IPTV video services.
Feature
l Support port-based rate limitation and bandwidth control;
l In compliant with IEEE802.3ah Standard
l Up to 20KM transmission Distance
l Support data encryption, group broadcasting, port Vlan separation, RSTP etc.
l Support Dynamic Bandwidth Allocation (DBA)
l Support ONU auto-discovery/Link detection/remote upgrade of software;
l Support VLAN division and user separation to avoid broadcast storm;
l Support power-off alarm function, easy for link problem detection
l Support broadcasting storm resistance function
l Support port isolation between different ports
l Support ACL and SNMP to configure data packet filter flexibly
l Specialized design for system breakdown prevention to maintain stable system
l Support software online upgrading
l EMS network management based on SNMP, convenient for maintenance
Specification
Item |
Parameter |
PON Interface |
1 GEPON optical interface |
User Ethernet |
4*10/100Mauto-negotiation |
|
PON Optical Parameter |
Wavelength: Tx 1310nm, Rx1490nm |
Data Transmission |
PON Throughput: Downstream 950Mbps; Upstream 930Mbps Packet Loss Ratio: <1*10E-12 |
Business |
Layer 2 wire speed switching Support VLAN TAG/UNTAG, VLAN conversion Support Port-based speed limitation Support Priority classification Support storm control of broadcast Support RSTP |
Network |
Support IEEE802.3 QAM ONU can be remotely managed by OLT Support Remote management through SNMP and Telnet Local management |
Management |
Status monitor, Configuration management, Alarm management, |
LED Indicator |
PWR: Power up or down OPTIN: Optical Link Status LINK: ONU Registered ETH: Link Status of Ethernet Interface LAN: Link Status of Ethernet Interface WIFI: WIFI status |
Shell |
Plastic casing |
Power Supply |
External 12V 0.5A AC/DC power supply adapter Power consumption: < 3.8W |
Physical |
Dimension: 160mm(L) x 120mm(W) x 30mm (H) Weight: 0.2kg |
Environmental |
Operating temperature: 0 to 50ºC |
WIFI Specification
Performance parameters |
Operating Mode |
Router or bridge |
Throughput |
IEEE 802.11b: 11Mbps IEEE 802.11g: 54 Mbps IEEE 802.11n: 135Mbps |
|
Frequency |
2.412 ~ 2.472 GHz |
|
Channel |
13*Channel, configurable to meet the standard of USA, Canada, Japan and China |
|
Modulation |
DSSS, CCK and OFDM |
|
Coding |
BPSK, QPSK, 16QAM and 64QAM |
|
RF receive sensitivity |
802.11b: -82dBm @ 1 Mbps; -80dBm @ 2 Mbps; -78dBm @ 5.5 Mbps; -76dBm @ 11 Mbps 802.11g: -82dBm @ 6 Mbps; -81dBm @ 9 Mbps; -79dBm @ 12 Mbps; -77dBm @ 18 Mbps; -74dBm @ 24 Mbps; -70dBm @ 36 Mbps; -66dBm @ 48 Mbps; -65dBm @ 54 Mbps |
|
RF output lever |
802.11b: 16.5 ±1dBm 802.11g: 13 ± 1dBm @ 54 Mbps; 14 ± 1dBm @ 48 Mbps; 15 ± 1dBm @ 6 ~ 36 Mbps 802.11n: 13 ± 1dBm @ 54 Mbps; 14 ± 1dBm @ 48 Mbps; 15 ± 1dBm @ 6 ~ 36 Mbps |
|
Encryption Mode |
802.11i security: WEP-64/128, TKIP (WPA-PSK) and AES (WPA2-PSK) |
Ordering Information
Product Name |
Product Model |
Descriptions |
ONU With Four FastEthernet Port and Built-in WiFi |
GONU1000W |
4*10/100M Ethernet interface, built-in WiFi, 1 GEPON interface, plastic casing, external power supply adapter |
