AC Three Phase Output 25kva-500kva Diesel Power Generator by USA Engine

Name: AC Three Phase Output 25kva-500kva Diesel Power Generator by USA Engine
Brand: Haiweineng
SKU: 109106855
Availability: InStock

US$ 2,000 - 100,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

Haiweineng

Model Number:

HCM

Fujian Haiweineng Electrical Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FUZHOU

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name Haiweineng

Model Number HCM

Output Type AC Three Phase

Speed 1500/1800rpm

Frequency 50/60Hz

Rated Power 20kw to 1000kw

Rated Voltage 110v to 440v

Rated Current 36A - 1800A

Below are prime imformation.Pls feel free to tell me if you need more details.Dwyane

Generator set power from 25kva to 1250kva

USA
Model	Rated Power		Standby Power		Engine	Alternator
Model	KW	KVA	KW	KVA	Engine	HWN Alternator
HCM25/s	20	25	22	27.5	4B3.9-G1	HWN-184F
HCM30/s	24	30	26.4	33	4B3.9-G2	HWN-184G
HCM37.5/s	30	37.5	33	40	4BT3.9-G2	HWN-184H
HCM40/s	32	40	35.2	44	4BT3.9-G2	HWN-184J
HCM50/s	40	50	44	55	4BTA3.9-G2	HWN-224D
HCM60/s	48	60	52.8	66	4BTA3.9-G2	HWN-224E
HCM85/s	68	85	74	93	6BT5.9-G1	HWN-224G
HCM100/s	80	100	88	110	6BT5.9-G2	HWN-274C
HCM125/s	100	125	110	138	6BTA5.9-G2	HWN-274D
HCM140/s	112	140	120	150	6BTAA5.9-G2	HWN-274E
HCM150/s	120	150	132	165	6CTA8.3-G2	HWN-274F
HCM180/s	144	180	160	200	6CTA8.3-G2	HWN-274G
HCM200/s	160	200	176	220	6CTAA8.3-G2	HWN-274H
HCM250/s	200	250	220	275	6LTAA8.9-G2	HWN-274K
HCM313/s	250	313	275	345	NTA855-G1B	HWN-314D
HCM350/s	280	350	308	385	NTA855-G2A	HWN-314E
HCM375/s	300	375	330	413	NTA855-G2A	HWN-314FS
HCM413/s	330	413	363	454	NTAA855-G7A	HWN-314F
HCM450/s	360	450	396	495	KTA19-G3	HWN-354C
HCM500/s	400	500	440	550	KTA19-G4	HWN-354D
HCM550/s	440	550	484	605	KTAA19-G5	HWN-354ES
HCM600/s	480	600	528	660	KTAA19-G6A	HWN-354FS
HCM625/s	500	625	550	688	KTAA19-G7	HWN-354F
HCM750/s	600	750	660	825	KTA38-G2	HWN-635B
HCM800/s	640	800	704	880	KTA38-G2A	HWN-635D
HCM900/s	720	900	792	990	KTA38-G2A	HWN-635E
HCM1000/s	800	1000	880	1100	KTA38-G5	HWN-635F
HCM1250/s	1000	1250	1100	1380	KTAA38-G9A	HWN-635G

Generator Data

Genset model		HCM25(open type)
		HCM25/s (silent type)
Frequency		50Hz/1500rpm, 60Hz/1800rpm
Voltage		110/220, 220/380, 230/400,
		240/415, 254/440V
Rated power		20kw/25kva to 1000kw/1250kva
Alternator		HWN /Stanford/Lerry somer/others
Phase		3 Phase or 1 Phase
Aspiration		NA / TC
Fuel tank capacity		8-12 hours fuel tank
Start system		Electric
Governing system		Electric
Silent level		60dB-70dB at 7m
