Diesel Engine Generator Set Power

Specifications

Generator Set Power
1.Stamford Technology Alternator
2.Price is lower 20%~30% than other brand

Main Product: diesel engine, diesel generator, alternator and spare parts;

Diesel Engine Usage: Widely used for generator set, boat, wheel loader, truck, water pump, sand pump,

                                 fire pump, construction machine, etc;
Diesel Engine Power Range: from 20kw up to 700kw;

Diesel Generator Power Range: from 30kw up to 700kw.



Diesel Engine Generator Set Power Technical Parameters

Genset Model (LD Brand)		LD128GF
Rated Power/Speed (kw/r/min)		128/1500
LD Diesel Engine	Engine Model	LD6CT8.3-G1
	Rated Power/Speed kw/r/min	133/1500
	Type	Vertical,inline,water-cooled,four stroke
	Intake Way	Turbocharged
	Number of cylinders×bore×stroke(mm)	6-114×135
	Total dispalcement(L)	8.3
	Min fuel consumption (g/kw.h)	≤195
	Starting type	Electric
	Speed governor model	Mechanical
	Oil capacity(L)	20~22
	Low noise limit dB(A)	98
Wattek Alternator (Stamford Technology)	Alternator nodel	274F
	Rated voltage(V)	400/230 or 380/220
	Current(A)	202
	Freq(Hz)	50 or 60
	Regulator approach	AVR
	Power factor(CosØ)	0.8 Lagging
	Phase	3Phase 4Wire
	Insulation Class	F/H
	Protection Class	IP22/IP23
Genset Packing	Net weight(kg)	2200
	Genset dimension L*W*H(mm)	3300×1150×1500



 Diesel Engine Generator Set Power Maintenance Service

1.Warranty interms will be issued by our factory,which is simple and quick;

2.Warranty period will be 12 monthes or 1500 working hours from commissioning date;

3.Parts replacement under warranty will be sent(include sea freight and insurance)to buyers witthout charges;

4.Easy torn parts are excluded in the warrenty,like plugs,condenser,fuse,battery,seal;

5.Problems cased by customer's incorrect man-made operation will be covered by the user;

6.Part use for overhaul and ordinary maintance will be offered by us in factory price;

7.Skillful engineers of us are available dispatched top cuatomers palce for training and service.
