Fire Fighting Power Range From 22kw up to 507kw, speed: 2900rpm, 3000rpm
Diesel engine is equipped with aluminum radiator, output shaft, 24V starter motor, filter(air filter, fuel
filter & oil filter), standard muffler, Clarke form control panel, selector switch, stop button, tachometer
with hourmeter, oil pressure gauge, water temperature gauge, battery charging light, stop solenoid valve.
Fire Fighting Equipment Diesel Engine for Fire Fighting Specifications
| Model | 6BTAA5.9-205G |
| Type | Vertical,Water-cooled,Four-stroke, Direction-injector |
| Number of Cylinders | 6 |
| Bore’stroke (mm) | 102*120 |
| Rate Power (KW) | 150 |
| Rate Power (HP) | 205 |
| Rate Speed (r/min) | 3000 |
| Total Displacement (L) | 5.9 |
| Max.Torque (N.m) | 640 |
| Speed at Max.Torque (r/min) | 1700~2000 |
| Min.specific Fuel Consumption at Full Load(g/kW.h) | ≤215 |
| Direction of Crankshaft Rotation (Facing to Flywheel) | Counter clockwise |
| Cooling Method | Forced Water Cooling |
| Lubricating Method | Pressure and Splash Lubricating |
| Starting Method | Electric Starting |
| Net Mass (kg) | 470 |
Fire Fighting Equipment Diesel Engine for Fire Fighting Features
| Engine Feature | Lower oil/fuel consumption; lower noise; Small vibration |
| Combustion Type | Direct Injection |
| Usage | For Fire Fighting |
| Control panel |
Clarke Form |
| Engine Speed | 2900rpm/3000 rpm |
| Maintanence Spare Parts | Genuine Engine Parts |
| Cylinder Block Material | Alloy Cast Iron |
| Max Overhaul | More than 15,000 hours |
| Factory Production Period | Within 4 days |
Fire Fighting Equipment Diesel Engine for Fire Fighting Service
1.Warranty iterms will be issued by our own factory, which is simple and quick;
2.Warranty period will be 12 monthes or 1500 working hours from commissioning date;
3.Parts replacement under warranty will be sent (include sea freight and insurance) to buyers freely;
4.Easy torn prts are excluded in the warranty, like plugs, condenser, fuse, battery, seal;
5.Problems caused by customer's incorrect man-made operation will be covered by the user;
6.Part use for overhual and ordinary maintanence will be offered by us in factory price;
7.Skillful engineers of us are available dispatched to customers place for training and service.
|
Ms. Kitty Lai Sales Manager Tel: +86 130 8772 3334 Fax: +86 (0)772 2875155 Email:longdao01(at) |
