LD120GF CE Approved Manufacturer AC 3 Phase 4 Wire 150kva Diesel Generator

Name: LD120GF CE Approved Manufacturer AC 3 Phase 4 Wire 150kva Diesel Generator
Brand: LD Brand
SKU: 109100825
Availability: InStock

US$ 6,800 - 8,050 MOQ: 1 Set

Key Specifications

Place of Origin:

Guangxi, China

Brand Name:

LD Brand

Model Number:

LD120GF

Liuzhou Long Dao Industrial And Trading Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangxi, China

Brand Name LD Brand

Model Number LD120GF

Output Type AC Three Phase

Speed 1500, 1800 r/min

Frequency 50, 60 HZ

Rated Power 120KW/150KVA

Rated Voltage 400/230V, 380/220V

Rated Current 216 A

Specifications

1. Germany, Yuchai, Technology
2. Price less 20%~30% than other brand
3. ISO9001, CE Certificates
4. Share Yuchai Parts

CE Approved Manufacturer AC 3 Phase 4 Wire 150kva Diesel Generator

LD diesel Generator is design and manufacture by our factory HD Power Co.,Ltd, which we has been

specialized in this power machine field more than 15 years; a morden engines and generator set production line

is built! Now our facotry have approve ISO9001:2008 and CE certiicates. Base on good quality and super

experience in our LD generator set, products have sold to all over the world, country like Thailand, Indonesia,

Laos, Albania, Haiti etc.

LD diesel geneartor technology is origin from Yuchai, Shangchsi, Germany FEV conpanies; For our LD

80~180KW diesel generator set, we assembly it with our own produced LD6B, 6LA Series diesel engines,

which is 6 cylinder, 4 stroke, power range from 90kw~215kw in 1500rpm and 1800rpm;

l Engines Applications Equipped our own LD6B, LD6LA engines, lower fuel consumption, lower noise,

convenient maintanecne and share spare parts with Yuchai Engines parts supply system;

l Alternator & Controller Wattek brand alternator 274, by Stamford technoloty; Smartgen controller 6120;

l Genset Characteristics 24V Electric start; radiator can meet environment temperature 50 degree;

Genset Model (LD Brand)		LD80GF	LD100GF	LD120GF	LD150GF	LD160GF	LD180GF
Rated Power/Speed (kw/r/min)		80/1500	100/1500	120/1500	150/1500	160/1500	180/1500
LD Engine	Engine Model	LD6B135Z	LD6B170L	LD6B210L	LD6LA245L	LD6LA265L	LD6LA285L
	Rated Power/Speed kw/r/min	90/1500	114/1500	139/1500	165/1500	176/1500	192/1500
	Type	Vertical,inline, water-cooled, four stroke
	Intake Way	Turb	Turbocharged & Inter-cooled
	No-cylinder×bore×stroke (mm)	6-108×125			6-108×140
	Total displacement(L)	6.9			7.7
	Min fuel consumption (g/kw.h)	≤205	≤195	≤200	≤195
	Starting type	Electric
	Speed governor model	Mechanical			Electric
	Oil capacity(L)	14-17			18-20
	Low noise limit dB (A)	≤102
Wattek Alternator	Alternator model	274C	274D	274E	274G	274H	274J
	Rated voltage (V)	400/230 or 380/220
	Current( A)	144	180	216	270	288	324
	Freq( Hz)	50 or 60
	Regulator approach	AVR
	Power factor (CosØ)	0.8 Lagging
	Phase	3Phase 4Wire
	Insulation Class	F / H
	Protection Class	IP22 / IP23
Genset Packing	Net weight (kg)	1800			2200
	Dimension LWH (mm)	3100×1150×1450			3300×1200×1550
