Servo Motor Encoder, UVW Signals Motor Rotary Encoder, 8mm Hollow Shaft Rotary Encoder (IBEST)
US$ 50 - 65
MOQ: 2 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
IBEST
Model Number:
IHU4808 series
Payment & Shipping
Payment Methods:
Port of Shipment:
Zhongshan Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UVW Servo Motor Rotary Encoder, DC AC Motor Rotary Encoder, 8mm Servo Motor Hollow Shaft Optic Rotary Encoder (IBEST)US$ 50 - 65MOQ: 2 Pieces -
10mm Shaft Rotary Encoder, 5000 PPR Optical Rotary Encoder, CNC Lathe Rotary Encoder, Connector Type DC Rotary Encoder (ISC5810)US$ 50 - 60MOQ: 2 Pieces
-
ISC5810 Rotary Encoder, Solid Shaft Optical Rotary Encodr, Optic Shaft Encoder, CNC Machine Encoder (IBEST)US$ 45 - 55MOQ: 2 Pieces
-
ISL5815 Flange Optical Rotary Encoder, CNC Machine CNC Lathe Rotary Encoder, Weaving Machine Rotary Encoder (IBEST)US$ 50 - 70MOQ: 2 Pieces
-
ISL5810 Flange Rotary Encoder For CNC Machine,CNC Lathe Rotary Encoder,textile Machine Rotary Encoder (IBEST)US$ 50 - 70MOQ: 2 Pieces
Place of Origin
Guangdong, China
Brand Name
IBEST
Model Number
IHU4808 series
Max. Current
100mA
Max. Voltage
DC 5V
Mechanical Life
100 M times
Specifications
UVW Servo Motor Rotary Encoder1.IHU4808 series,Cable radial connect
2.5V DC ;Liner driver output
3.Pluses:1000,1024,2048p/r
1.FEATURES of IHU4808 UVW Rotary Encoder For Servo Motor :
- Adapt to the spring connect with the electrical ended, suit to the servo motor.
- External diameter 48*42mm, the fixture mouth is 9*15mm, (the taper is 1: 10) side the aerial socket entry.
- It has the UVW signal of the test AC motor position.
- Signals: ABZ, A-B-Z-, UVW, U-V-W-
- DC 5 V TTL output
- Impulse per revolution: 1000, 1024, 2048, 2000, 2500 are optional.
2.Technical specification
| Property project | Specific parameter |
| Out wave & duty ratio | square wave & 0.5T±0.1T |
| Current Consumption | ≤160mA |
| Response frequency | 0-120KHz |
| Max.permissible revolution | 6000rpm |
| Moment of inertia | 4.0*10-6Kg.m2 |
| Starting torque | 2.5*10-3Nm |
| Shaft loading | Radical:20N / Thrust :10N |
| IP rating | IP54 |
| Operate & Stock temperature | -30C-100C / -25C-80C |
| Ambient humidity | 30-85%(with no condensation) |
| Power supply | DC+5V±5% / +5-12V / +12-24V |
| Shock resistance | 980m/s2,6ms,2 times each in X,Y,Z directions |
| Vibration resistance | 50m/s2,10-200Hz,2 times each in X,Y,Z directions |
| Operating life | MTBF≥30000h (+25C,2000rpm) |
| Output voltage | Vh≥85% Vcc,Vi≤0.3V |
| Weight | 0.15kg |
Our company is a professiona manufacutures of:
1, Sensors: inductive proximity sensor, capacitive proximity sensor, photo sensor, hall sensor, color mark sensor and analog sensor.
2, Digital meter: temperature controller, digital counter, digital timer, digital frequency/tacho/linespeed meter, digital panel meter, analog panel meter ...etc.)
3, Solid state relay: single phase and 3 phase
4, Rotary encoder and couplings
5, Various type of cable and connectors..etc.
6, Pressure transmitters.
7, Safety light curtain.
Welcome to contact us!
