Large flow pressure relief valve
Characteristics:
1.Can control the pressure after valve very well when the flow has a great change.
2.Can play a role very well at the occasion from primary relief to the low pressure system.
3.Used for a variety of gas filling, water treatment, and other various industrial pneumatic environment
4.24 in large diaphragm design.
5. Proper material adopts 316L stainless steel.
6. Installed with plate can be chosen.
7. Max inlet pressure: 3600psi(248.2bar).
8. Outlet pressure range: 0 to 500psi(34.4bar).
9. Discharge coefficient:(Cv)1.0
10.Weight: 1.45kg.
11.Max using temperature:℃(℉):Teflon:66(150) PCTFE:80(175) PEEK:260 (500) Viton:121(250)
12.Max inlet pressure:psi(bar ):Teflon:1000(68.9) PCTFE:3600(248.2) PEEK:3600(248.2) Viton:250(17.2).
13. Pls make sure the using temperature, pressure,medium before choosing the product.
14. All of the 316L stainless steel meets the ASTM standard.
15.All of the Teflon,PCTFE,PEEK,Viton sealing material adopts imported bar material for precision machining.
| Specification | T1-FM-TY-C |
| Product name | Large flow pressure relief valve |
| Model description | 316 material regulator,3600psi(248.2bar),Cv1.0,1.45kg. |
