Tesla Meter Multi-function Pointer

Name: Tesla Meter Multi-function Pointer
Brand: Yunyi
Availability: InStock

FOB Price

US$ 80 - 150 / Unit

1 Unit(Min. Order)

Port beijing tianjin shanghai shenzhen
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shaanxi, China	Brand Name	Yunyi
Model Number	SG	Power	Other
Usage	Other

Packaging Details

Tesla meter multi-function pointer
Corrugated cardboard boxes outer and foam paper inner packing size: 4x5x14dm

Product Description

Tesla meter multi-function pointer

Description of tesla meter multi-function pointer :

Multi-function pointer tesla meter hall element linearity is good to the use of the measuring probe, and USES the magnitude 0.5 meter for the output, according to a linear scale, 10 range, respectively is 5 mt, 10 mt, 20 mt, 50 mt, 100 mt, 200 mt, 500 mt, 1 t and 2 t, 5 t, of the strong field measurement precision is better than that of 1.5% (full).

Technical indicators of tesla meter multi-function pointer :

1, Maximum range 5 t, the highest resolution 0.05 mT (Gs 0.5).

2, Accuracy (20 mT ~ 1 t) 1.5% or less (10 mT, 2 t) 2.5% or less

3, Can according to the requirements of different probe calibration instruments, more than one machine can match the probe.

4, Have analog output, output value of 1 mV/mT (1) access to digital dc voltage range, which become a digital tesla meter; (2) access to digital ac voltage range or ac millivoltmeter, becomes a communication digital tesla's plan; (3) access to the oscilloscope or function recorder, can observe magnetic field changes with the peak and the magnetic field distribution curve.

5, B value comparison function, apply to factory for sieving and inspection of magnetic materials or components.

6, There are full range alarm, the reverse magnetic field or super limiter circuit, allowed used in pulse magnetic field

Company Profile

Xi'an Yunyi Instrument Co., Ltd.

Xian Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer, Mr Tian has more than 30 years experience on this area, and he is one of the engineers who introduced the Rosemount technology. We are specialized in developing pressure transmitter, etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
