Electric contact pressure gauge bimetal thermometer

Standard export package

Specifications

Electric contact pressure gauge bimetal thermometer
1.experienced manufacturer
2.bimetal thermometer
3.CE

Electric contact pressure gauge bimetal thermometer



Description:

Electric contact bimetallic thermometers WSSX series used in production field of temperature control and alarm automatically.Direct measurement of various production process - 80 ~ 500 °C range, steam and gas medium temperature.

Features:
The scene display temperature, intuitive and convenient;
With functions of automatic cut off power and alarm.
Safe and reliable, long life;
Many kinds of structure forms, can meet different requirements.
working principle
WSSX lectric contact bimetallic thermometers  is the use of lead contact changes when temperature changes,When contact with the upper and lower limits or disconnected at the same time,The circuit of relay action,To control and alarm automatically.
Main technical parameters
Product performance standards JB/T8803-1998  GB3836-83
Dial nominal diameter:100
accuracy class:(1.0),1.5
thermal response time:≤40s
Protection grade: IP55
Normal working atmosphere conditions: temperature - 25 ~ + 55 °C, relative humidity≤85%.
Set point error:Set point error should not exceed the basic error of 1.5 times.
differential gap:Change-over difference should not exceed the basic error of 1.5 times.
Switch the repeatability:Bimetallic thermometer repeatability limit range switch is not greater than the absolute value of the basic error limits 1/2.



Parameter:

rated power VA	maximum working voltage V	maximum working voltage
10	220 a.c	0.7A



Type and specification



Type	Range	Accuracy class	Protecting  tube material	Specification	install fixed device
WSSX-400/500	-80~+40 -40~+80 0~50 0~100 0~150 0~200 0~300 0~400 0~500	1.5	1Cr18Ni9Ti 304 316 316L B C-276	75 100 150 200 300 400 500 750 1000	No fixed device
WSSX-401/501
WSSX-480/580
WSSX-401/501					Movable external thread
WSSX-411/511
WSSX-481/581
WSSX-402/502					Movable internal thread
WSSX-412/512
WSSX-482/583
WSSX-403/503					Fixed screw thread
WSSX-413/513
WSSX-483/583
WSSX-404/504					mounting flange
WSSX-414/514
WSSX-484/584
WSSX-405/585					Adjustable thread joint
WSSX-415/515
WSSX-485/585
WSSX-406/506					Card flange
WSSX-416/516
WSSX-486/586
