PD 2400 Dry block temperature calibrator

Dry block temperature calibrator export packing

Specifications

Dry block temperature calibrator
1 professional manufacturer
2 quick shipment
3 CEcertification

Dry block  temperature calibrator



Description:

The Temperature Calibrators have a built in PID Temperature Indicator Controller for Reference & also for controlling the temperature of the Dry Block as per selection from the front keys. Accurate temperature can be maintained in the Dry Block Temperature Calibrator uniformly using the PID Controller.

Standard supply includes FL 11 Dry Block, Temperature Calibrator, 6 hole insert, Clamp, Power Cord and Calibration Certificate traceable to National Standards. Standard Temperature Ranges available are 50 to 600 Deg. C with an accuracy of /-0.7 Deg. C. Other temperature ranges are also available on request.



Features:

Insertion depth was seized in the same industry-leading level of temperature field, the vertical temperature field well.

Digital temperature control, rapid heating and rapid cooling, easy setup, good temperature stability.

Large-screen display window, intuitive, eye-catching.

Soaking the block can be replaced.

You can use instead of freezing the bottle.

Small size, light weight, easy to carry, no pollution.

With RS232 or RS485 interface, allowing the user to easily select the bus mode.

Furnace built-in load short circuit, the load circuit, sensor protection and a series of protection.



Technical parameters:

1 temperature occur: within ambient temperature -25 °C ~ 125 °C.

2 Accuracy: Display Accuracy: ± 0.5 °C.

3 temperature fluctuation: ≤ ± 0.02 °C / 15 min.

4 the horizontal temperature field: ≤ ± 0.05 °C (temperature field tests using special soaking block).

5 the vertical temperature field: From the bottom of the hole counting soaking block within the range of temperature variation is not more than 50mm 0.6 °C.

6  insertion depth: 180mm.

7 both the number of sensors can be inserted into the thermal block and Aperture: standard configuration for three holes, respectively  6,  8, 10mm.

8  power: 150w.

Note: both the outer diameter of the heat block is 25mm, please specify when ordering the sensor was seized was seized sensor insertion depth and diameter size, special needs, both sides further deliberations.







Dimensions and weight

Dimensions: Length 290mm X width 150mm X height 320mm.

Weight: 7.5Kg (with 180mm deep, for example)

Use of the environment:

Temperature: (0 ~ 50) °C.

Relative humidity: ≤ 95%.

Air pressure: 86kPa ~ 106kPa.

Power supply: 220VAC; 50Hz.

Surrounding non-corrosive gases, flammable gases.
