Home > Products > Temperature products > YDK322 Smart Temperature Transmitter
YDK322 Smart Temperature Transmitter
- 1000 Piece / Pieces per Month
- Any port of China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Transmitter Temperature Sensor and Transmitter
-
Temperature Measurement Electronic temperature transmitter
-
Electronic Indicating Temperature Transmitters price
-
Specialist in industrial temperature measurement pressure transducer
-
Temperature Transmitters / Transducers /Instrument
-
temperature pressure gauge
Product Details
| Place of Origin | Shaanxi, China | Brand Name | Yunyi | |
| Model Number | YDK322 |
Standard export package
Product Description
Features of Integrated Temperature Transmitter :
1 Can wire transfer. Signal converter powered two wire output signal is also transmitted
2 Constant current or constant voltage signal output signals, anti-interference ability, good remote performance.
3 Signal converter uses epoxy encapsulated into modules, with anti-vibration, corrosion, moisture, etc., can be used in places with poor conditions.
4 Thermocouple millivolt signal by the signal converter is directly converted into 4 ~ 20mA current output, with ordinary cable to transmit signals, eliminating the need for expensive wire compensation.
5 Temperature transmitter with on-site display of both current signal 4 ~ 20mA output, but also in the field temperature reading measured temperature, bring great convenience to the operator.
6 High precision, interference, long-term stability, maintenance-free, can be remote (most far 1000 m). performance;
Technical parameters of Integrated Temperature Transmitter :
| Range | -200 ~ 1800 °C |
| General Accuracy | ± 0.25% |
| Supply voltage | 13 ~ 30V, DC |
| Load Resistance | 0 ~ 850Ω |
| Output signal | 4 ~ 20mA |
| Basic error | ± 0.2%, ± 0.5% |
| Display | LCD |
| Ambient Temperature Effect | 0.25% / 10 °C |
| Cold junction compensation error | 0.5% / 10 °C |
| Ex-mark | d Ⅱ BT4 |
| Protection | IP65 |
| Input type | RTD, Pt100, second-or third-line thermocouple (all known types) |
| Ambient temperature | -40-85 °C, with display type is -10-70 °C |
| Humidity | 0-95% RH, non-condensing |
| Display | Digital LCD display pointer table or optional |
| Protection tube material | 1Cr18Ni9Ti or ceramic or steel jade tube |
Standard export package and fast delivery.
We supply twenty-four- hour on line service, and we will reply your message within 12 hours.
About the payment, we accept all kinds of payment terms, such as L/C, TT, Western Union,Escrow, etc.
Xi'an Yunyi Instrument Co.,Ltd has been the professional manufacturere of kinds of pressure gauge, pressure transmitter, pressure regulator, valve products and dead weight tester for many years. And our products have been sold to many countries, such as United States, United Kingdom, Brazil, Russia, Malaysia, Israel, etc. and get high praise from our clients. If anything we can help, let us know freely, we are sure we will be the best
supplier for you.
Company Profile
Xian Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer, Mr Tian has more than 30 years experience on this area, and he is one of the engineers who introduced the Rosemount technology. We are specialized in developing pressure transmitter, etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
