Specifications
Shock-proof bourdon tube pressure gaugehigh quality and low price
ce approval
Shock-proof bourdon tube pressure gauge
Description of Shock-proof bourdon tube pressure gauge:
Shock-proof bourdon tube pressure gauge is suitable for the severe vibraton environment, can tolerate the pulsation, impact and sudden unloading of the medium. Widely used in machinery, petroleum, chemical industry, metallurgy, mining and electricity etc, to test the pressure of medium that without corrosive effect on the copper and copper alloy.
Specification of Shock-proof bourdon tube pressure gauge:
Type |
Structure |
Accuracy(%) |
Range(MPa) |
Environmental |
YTN-60 |
diameter without brim |
±2.5 |
0~0.16 0~0.25 0~0.4 0~0.6 0~1.0 0~1.6 0~2.5 0~4 0~6 0~10 0~16 0~25 0~40 0~60 |
Temperature of the surrounding environment : -5~55°C;-25~55°C.
Using work environment vibration frequency No more than 25 hz, amplitude is not more than 1 mm |
YTN-60T |
diameter with back brim |
|||
YTN-60Z |
axle without brim |
|||
YTN-60ZT |
axle with front brim |
|||
YTN-100 |
diameter without brim |
±1.6
±1.0
|
0~0.16 0~0.25 0~0.4 0~0.6 0~1.0 0~1.6; 0~2.5 0~4 0~6 0~10 0~16 0~25 0~40 0~60; 0~100 0~160;0~250 -0.1~0.5;-0.1~0.9;-0.1~1.5 -0.1~2.4 -0.1~0 |
|
YTN-100T |
diameter with back brim |
|||
YTN-100Z |
axle without brim |
|||
YTN-100ZT |
axle with front brim |
|||
YTN-150 |
diameter without brim |
|||
YTN-150T |
diameter with back brim |
|||
YTN-150Z |
axle without brim |
|||
YTN-150ZT |
axle with front brim |
About Us:
Xi'an Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer Mr Tian has more than 30 years on this area, he is one of the engineers who introduced the Rosemount technology. We specializing in developing high precision pressure transmitter and pressure gauges. And we also develop temperature transmitter, level transmitter, densitometer etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
