high pressure oil pump pressure calibrator
Features
Imports made pump, safe, reliable, non-blocking
Spiral buck, buck smooth, easy to operate return test
The most advanced sealing technology, long life, no leakage
Ultra-fine tuning, more precisely controllable pressure change
Open architecture for easy cleaning and maintenance
3 output ports, you can also check two tables, a plurality of output ports can also be customized according to customer needs
Output port using fast union, without dismantling the instrument can easily wrench
The factory with sophisticated portable aluminum suitcase.
Technical Parameters
Pressure range:
XY-2003A-30M: 0 ~ 30MPa (hydraulic oil) XY-2003B-60M: 0 ~ 60MPa (hydraulic oil)
XY-2003C-100M: 0 ~ 100MPa (hydraulic oil) XY-2003D-160M: 0 ~ 160MPa (hydraulic oil)
XY-2003E-200M: 0 ~ 200MPa (castor oil) XY-2003F-250M: 0 ~ 250MPa (castor oil)
Output size: M20 * 1.5 (based on field instrumentation interfaces can provide a variety of different adapters, see pressure accessories)
Minimum controllable amount of adjustment: 0.2MPa
Fuel tank capacity: 700ml
Dimension: 410mm × 310mm × 180mm (8003A type 410mmX310mmX120mm)
Weight: 10kg (8003A-type weight 5kg)
