Manual Pressure Test Pump

manual pressure test pump
Corrugated cardboard boxes outer and foam paper inner

manual pressure test pump

Desicription of manual pressure test pump :
manual pressure test pump is a portable pressure pump.For field installation of instrument calibration in the industrial process and control of indoor use all kinds of pressure gauges.Can also provide pressure source correction table for pressure measuring instrument manufacturer.All kinds of pressure transmitter within every 60 M pa,Pressure sensor and all kinds of pressure gauges Check all available hand pressure pum.

Features of manual pressure test pump :
1.Portable, light weight,,Suppression of light.Easy to use Structural design pressure fine-tuning hand,Rotate the fine-tuning hand can easily change the output pressure.Also comes with a high-pressure hose connection is timing
,Meter connector connect pressure gauge .
2.Hand pressure pump is the handle, the piston rod. Through gas, pump cover, put the oil hand, fine-tuning hand, form joint, etc .rotation.

Specifications of manual pressure test pump :
Output pressure range: 0-1.6MPa, -0.1-0MPa, 0-25MPa
Operating temperature: -20~50C
Operating relative humidity: 0~100%
Flexible hose connector: M20*1.5 female
Master gage connector: 1/4NPT male
Dimensions: 235×120×65 230 x 110 x 60
Weight: 0.6kg 0.5kg
Accessories: 500 mm long plastic hose and a leatherette carrying bag
Outlet threads: 1/4 NPT, or to custom request
Vernier-adjuster: micro-adjustable, volume control
