Specifications
Hydraulic Dead Weight Testers1.It is simple in structure, high reliability.
2.Convenient operation and maintenance.
Hydraulic Dead Weight Testers (Accuracy : 0.015% )
Description of Hydraulic Dead Weight Testers :
1.The working position of piston is monitored by displacement sensor, which makes piston gauge more sensitive and accurate.
2. Low gravity center of loads , piston rotating steadily and pressure fluctuating obscurely too much.
3. Novel seal structure and excellent properties.
4. Pump, pressure regulator , valve and pipe can be used conveniently because of reliability, portability and perfection.
specifications of Hydraulic Dead Weight Testers :
1.wide range
2.Accuracy: 0.05%; 0.02% ;;0.01%; 0.005%.
Model |
Measuring range |
JYB-0.25 |
-0.1-0.25Mpa |
JYB-0.6 |
0.04-0.6Mpa |
JYB-6 |
0.1-6Mpa |
JYB-60 |
1-60Mpa |
JYB-100 |
1-100Mpa |
JYB-160 |
1-160Mpa |
JYB-250 |
1-250Mpa |
Hydraulic Dead Weight Testers of Operating Principle:
Fluid Pressure generated by a screw pump acts on the bottom of a vertically free floating piston. The force produced pushes the loaded free piston vertically upwards. The piston floats freely in its cylinder and the pressure in the circuit will be determined by the weights loaded on the piston divided by the effective area of the piston with corrections for value of acceleration due to gravity, air buoyancy, surface tension and datum level difference.
About Us:
Xi'an Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer Mr Tian has more than 30 years on this area, he is one of the engineers who introduced the Rosemount technology. We specializing in developing high precision pressure transmitter and pressure gauges. And we also develop temperature transmitter, level transmitter, densitometer etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
If you need this Hydraulic Dead Weight Testers, please visit the websit
