Mobile crusher/movable impact crusher/portable crusher for sale
1. Description of mobile crusher/movable impact crusher/portable crusher for sale
Mining machine mobile crusher is applies to such materials whose length of side does not surpass
500mm, the compressive strength does not surpass 320Mpa. It is better to granite, the limestone, the
river pebbles,and so on.
Mobile crusher is suitable for crushing soft, hard and super hard materials, which is widely used
in smelting, building materials, highway, railway, water conservancy, chemical industry and many other
departments.Mobile crusher is also the important equipment of mining machinery.
2.Features of mobile crusher/movable impact crusher/portable crusher for sale
1.High reliability, excellent performance
2.Easy transportation, short assembly time
3.Simple operation and repair, which can meet the stringent environmental standards.
3.Operating principles of mobile crusher/movable impact crusher/portable crusher for sale
Materials are evenly sent to crusher via feeder; after having primarily crushed by impact crusher,
crushed materials enter circular vibrating screen and form closed circuit system, thus realizing circulating
crushing.Mobile impact crusher can remove circular vibrating screen according to actual production
requirements, thus realizing primary crushing of materials directly. This mobile crushing plant can be
used with other crushing equipment, which is of convenient operation and flexibility.
4. Technical parameters of mobile crusher/movable impact crusher/portable crusher for sale
| Model |
Transport Length (mm) |
Transport width (mm) |
Transport height (mm) |
Max Length (mm) | Max Heigth (mm) | Max width (mm) |
Belt conveyor Height(mm) |
Tire configuration | Total Weight (T) |
| YG93E69 | 12500 | 2450 | 4000 | 13200 | 4600 | 3100 | 2700 | Dual Axis | 42 |
| YG1142E710 | 14000 | 2450 | 4800 | 15000 | 5800 | 3300 | 2700 | Three Axis | 55 |
| YG1349E912 | 15500 | 3000 | 4800 | 17000 | 5800 | 3500 | 3000 | Rour Axis | 72 |
Chassis Height:1720MM Altitude Different between Tire and Chassis:380MM
| Model | Feeder | Jaw crusher | Belt conveyor |
Extended Belt Conveyor |
Capacity | Generator | Power |
| YG93E69 | GZD-960*280 | PE600*900 | B650*7M | Optional | 90-180t/h | Optional | 91.5KW |
| YG1142E710 | GZD-1100*4200 | PE750*1060 | B800*9M | Optional | 110-320t/h | Optional | 134KW |
| YG1349E912 | GZD-1300*4900 | PE900*1200 | B1000*11M | Optional | 220-450t/h | Optional | 146KW |
Pre-sales services
1.Guide customers to choose products which are best suitable for them.
2.Design and manufacture tailor-made products according to the specific needs of customers.
Sales services
1.Strict inspection before the delivery of equipment.
2.Arrange the delivering of goods in accordance with contract.
After sales services
1. Assist clients to prepare for the first construction scheme.
2. Install and debug the equipment.
3. Train the first-line operators on site.
4. Examine the equipment regularly.
5. Take initiative to eliminate the troubles rapidly at site.
6. Distribute the guarantee fittings door-to-door.
7. Provide perfect service.
8. Provide technical exchanging.
Henan Songshan Heavy Industry Co., Ltd., a state designated manufacturer by National Construction
Department,has a history of over 30 years in machine manufacturing.
We mainly specialize in manufacturing beneficiating , crushing and milling machines, such
as Jaw Crushers, Impact Crushers,Mobile Crushers, Cone Crushers,Double Roller Crushers,
Raymond Mills, Ultrafine Mills,Ball Mills, Flotation Separators, Magnetic Separators, Rotary kilns,Rotary Dryers, Shaking Tables and Sand Making Machines.
Our products have received the ministerial and provincial honors. Due to the high quality and perfect
after sales service, our products have won trust and good comments from our customers and taken the
lead in the machinery fields.
Company's certificate
Customer visiting
Customer site
Please don’t hesitate to inform us:
1.What's kind of your raw material?
2. What's your raw stone size?
3. What's the capacity ? (T/H)
4. What's the final stone size request?
5. Others?
