Home > Industrial Equipment & Components > Valve > Ball Valve > LPG Gas Regulator Price/LPG Gas Cylinder Pressure Regulator

LPG Gas Regulator Price/LPG Gas Cylinder Pressure Regulator

Name: LPG Gas Regulator Price/LPG Gas Cylinder Pressure Regulator
Brand: Yunyi
SKU: 109071301

LPG Gas Regulator Price/LPG Gas Cylinder Pressure Regulator thumbnail-1

LPG Gas Regulator Price/LPG Gas Cylinder Pressure Regulator photo-1

US$ 1 - 20 MOQ: 1 Piece

Key Specifications

Get Latest Price

Standard or Nonstandard:

Standard

Structure:

Other, According to the machine design

Pressure:

High Pressure

Contact Supplier Request Quote Chat Now

Xi'an Yunyi Instrument Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin/Qingdao/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Standard or Nonstandard Standard

Structure Other, According to the machine design

Pressure High Pressure

Power Other, According to the condition

Material Stainless Steel

Temperature of Media High Temperature

Media Gas

Port Size According to the machine design

Place of Origin Shaanxi, China

Model Number T1-FM-TY-H

Brand Name Yunyi

Gas cylinders switching regulator

Specification: T1-FM-TY-H

Product name: Gas cylinders switching regulator

Specification description: 316 material pressure regulation valve,6000PSIG,20-500 psig,Cv0.06.

Characteristic:

1.Installing two 316L stainless steel reducing valves on the standard stainless steel frame,make the inlet pressure reach to 6000psig,regulating the outlet pressure range from 0-10psig to 0-500psig and supplying the gas continuously.

2.Realize replace gas cylinder safely online with the process continued running.

3.Can be equipped with entrance with 50mm outer diameter pressure gauge and common use steel cylinder joint.

4.The entrance with 20um filter.

5.Power shut-off totally.

6.Export pressure regulating range: 10,25, 50, 100 ,250 ,500psig.

7.Max using pressure:6000PSIG.

8.Pressure switched setting range: 20-500 psig.

9.Sealing material is PCTFE and PEEK.

10.Cv value is 0.025,0.06 and 0.2.

11.Installing support can be fixed on the site, and easy to use.

12.Max using temperature:℃(℉):Teflon:66(150) PCTFE:80(175) PEEK:260 (500).

13.Max inlet pressure:Teflon:3600(248.2) PCTFE:6000(413.7) PEEK:3600(248.2). 14.Pls make sure the using temperature, pressure,medium before choosing the product.

15.All of the 316L stainless steel meets the ASTM standard.

16.All of the Teflon,PCTFE,PEEK,Viton sealing material adopts imported bar material for precision machining.
