Home > Products > Manifold valve > High Pressure Electric Regulator Valve, Natural Gas Pressure Reducing Valve
High Pressure Electric Regulator Valve, Natural Gas Pressure Reducing Valve
- Tianjin/Qingdao/Shanghai
- T/T L/C D/P D/A
You May Like
Product Details
| Standard or Nonstandard | Standard | Structure | Other, According to the machine design | |
| Pressure | Other, According to the condition | Power | Other, According to the condition | |
| Material | Stainless Steel | Temperature of Media | Other, According to the condition | |
| Port Size | According to the machine design | Place of Origin | Shaanxi, China | |
| Model Number | T1-FM-TY-F | Brand Name | Yunyi |
Standard export package
Product Description
Electric heating valve
Specification: T1-FM-TY-F
Product name: Electric heating valve
Specification description:316 material regulator 3600psi(248.2bar),0-193 ℃(380℉),Cv0.06.
Characteristics:
1. Supplying thermal energy for sampling medium entering into the instrument system.
2. Is used for preheating fluid and preventing the gas from concentrating or the fluid evaporating into gas before analysis.
3. Consists of heat exchange and pressure reducing two parts.
4. The Noumenon adopts 316L stainless steel.
5. Both of junction box and noumenon adopts explosion-proof design.
6. Power supply adopts 220v alternating voltage.
7. Heating temperature range:0-193 ℃(380℉).
8. Max inlet pressure:3600psi(248.2bar).
9. Outlet pressure range:0 to 500psi (34.4bar).
10.Discharge coefficient:(Cv)0.025 0.06(standard) 0.2
11.Max using temperature:℃(℉):Teflon:66(150) PCTFE:80(175) PEEK:260 (500) .
12.Max inlet pressure:psi(bar ):Teflon:3600(248.2) PCTFE:3600(248.2) PEEK:3600(248.2) .
13. Pls make sure the using temperature, pressure,medium before choosing the product.
14. All of the 316L stainless steel meets the ASTM standard.
15.All of the Teflon,PCTFE,PEEK,Viton sealing material adopts imported bar material for precision machining.
Company Profile
Xian Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer, Mr Tian has more than 30 years experience on this area, and he is one of the engineers who introduced the Rosemount technology. We are specialized in developing pressure transmitter, etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
