Specifications
stainless steel pipe fittingStem threads isolated from system fluid
Externally adjustable PTFE packing
Metal-to-metal shutof
stainless steel pipe fitting, Pneumatic valve SS-6BK-1C
Description: SS Bellows-Sealed Valve, Gasketed, PCTFE Stem Tip, 3/8 in. Tube Fitting, SC-11 Cleaned, NC Actuator
Specification of stainless steel pipe fitting, Pneumatic valve SS-6BK-1C:
| SPECIFICATION SUMMARY | |
| Actuator Type | Pneumatic |
| Body Material | Stainless Steel |
| Body Type | Straight |
| Flow Pattern | Straight (2-way) |
| Series | B Series |
| Service Class | General |
| End Connection 1 Size | 3/8 in |
| End Connection 1 Type | tube fitting |
| End Connection 2 Size | 3/8 in |
| End Connection 2 Type | tube fitting |
| Bellows Material | 321 Stainless Steel |
| Body Seal | Gasket with soft seat |
| Cleaning | SC-11 |
| Gasket | PTFE-coated 316 SS Gasket |
| ID Tag | No |
| Stem Type | Conical |
| Surface Finish | Standard |
| Testing | Helium leak testing according to SCS-00020 |
| Stem Tip Material | PCTFE |
| Actuator Operation Mode | Normally Closed Spring Return |
| Actuator Model | 1 Series |
| Bonnet Sniffer Tube | No Body Sniffer Tube |
| Indicator Switch | No Indicator Switch |
| Max Temperature Pressure Rating | 200°F @ 125 PSIG /93°C @ 8.6 BAR |
| Room Temperature Pressure Rating | 125 PSIG @ 100°F /8.6 @ BAR 37°C |
About Us:
Xi'an Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer Mr Tian has more than 30 years on this area, he is one of the engineers who introduced the Rosemount technology. We specializing in developing high precision pressure transmitter and pressure gauges. And we also develop temperature transmitter, level transmitter, densitometer etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
If you need this low price solenoid valve , please visit the website
