Specifications
liquid level transmitter made in China1 professional manufacturer
2 quick shipment
3CEcertification
liquid level transmitter
Description :
The instrument is equipped with a 2088-type shell structure using piezoresistive elements LSI and microcontroller technology and novel membrane keypad, so the product has anti-interference ability, good sealing performance, high accuracy, wide range, from water, oil to paste can be highly accurate measurements. Not measured media bubble, deposition affect electrical properties, no material fatigue wear, vibration, shock insensitive, widely used in water treatment plants, deep reservoirs, tanks, coal washing plant, equipped with a paste or slurry tank spaces.
Specification :
1 Measuring range: 0 ~ 20m
2 Output signal: two-wire 4 ~ 20mA (intelligent digital signal superimposed HART protocol)
3 Display: four LCD Display
4 Accuracy class: 0.25% F.S custom 0.5% F.S
5 Power supply voltage: 10 ~ 36VDC, recommended 24VDC. Almost no impact on the power change
6 Load resistance: ≤ 500Ω
7 Materials in contact with the measuring medium: 316 stainless steel or 1CR18N19T1
8 Working environment: -40 ~ 70 °C, humidity <85%, dry rot Environment
9 Explosion levels: ExiaiIICT6
Features:
1 All intelligent two-wire 4-20mA work, four LCD display.
2 Full digital calibration, without any movable potentiometer, lower drift.
3 Enhanced anti-jamming design, suitable for all kinds of harsh industrial environments electromagnetic environment.
4 Wide voltage design, reverse polarity and over-current protection.
About Us:
Xi'an Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer Mr Tian has more than 30 years on this area, he is one of the engineers who introduced the Rosemount technology. We specializing in developing high precision pressure transmitter and pressure gauges. And we also develop temperature transmitter, level transmitter, densitometer etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
If you need this digital level meter , please visit the website
