4-20mA Liquid Water Level Sensor
US$ 100 - 110
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Shaanxi, China
Brand Name:
Yunyi
Model Number:
YD322-II
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port of China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Input Type Fuel Level Sensor Made in ChinaUS$ 40 - 100MOQ: 1 Unit -
Measuring Instrument Liquid Water Tank Level Gauge Meter Sensor TransmitterNegotiableMOQ: 1 Piece
-
China Suppiler Liquid Water Tank Level Gauge Meter Sensor TransmitterNegotiableMOQ: 1 Piece
-
Best Selling Submersible Type Liquid Water Level Transmitter GaugeNegotiableMOQ: 1 Piece
-
Level Measuring Instruments Liquid Water Level Meter Transmitter GaugeNegotiableMOQ: 1 Piece
Place of Origin
Shaanxi, China
Brand Name
Yunyi
Model Number
YD322-II
4-20mA liquid water level sensor
YD322-II liquid level transmitter is compose of full sealed isolation membrane oil-filled level sensor and special instrument circuit. With the advantages of high measuring precision, good stability, long service life, convenient installation, etc.
With unique technology of sealing structure form, and good anti-leakage performance,
immersed in a liquid reliable operation for a long time.
Technical Parameters of YD322-II Liquid Level Transmitter
| Measurement object | liquid level of water, oil, paste |
| Measuring range | 0 - 200m |
| Output signal | 4 ~ 20mAor 0 ~ 10mA |
| Power supply voltage | 24VDC |
| Temperature | -20 to 80℃ |
| Index Table | user select |
| Material | die-casting aluminum alloy shell, epoxy coating surface |
| Diaphragm | 316 stainless steel |
| Probe | 1Cr18Ni9Ti |
| Pressure Range | 0-1 |
| Accuracy | ±0.1% |
| Power Supply | 24VDC (12-30VDC) |
| Signal Output | Two Wire: 4-20mA |
| Operating Temperature Range | -20 to 80℃ |
| Connection Size | Inputting Type: Φ22 or Φ27 |
| Medium | Liquid compatible with 316LSS |
