4-20ma analog auto level instrument price,leveling gauge for machine,electronic level gauge
- 5000 Unit / Units per Month
- shenzhen beijing tianjin shanghai
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Place of Origin: | Shaanxi, China | Brand Name: | Yunyi | Model Number: | YD322 |
Packaging Details
4-20ma analog auto level instrument price,leveling gauge for machine,electronic level gauge
Corrugated cardboard boxes outer and foam paper inner packing size: 4x5x14cm
Product Description
4-20ma analog auto level instrument price,leveling gauge for machine,electronic level gaugege
Principle of level gauge :
Input type (Hydraulic pressure) liquid level transmitter adopt high performance diffused silicon piezoresistive pressure sensor as measuring element, after the high reliability of amplification circuit and precise temperature compensation, convert the gauge pressure or absolute pressure of the measured medium into standard voltage or current signals.
This product has the advantages of small volume, convenient use and installation, directly put into the water, that can measure liquid height from the surface to the end of the liquid level transmitter.
Feature of China supplier level gauge :
Use advanced circuit processing technology, stable performance and high sensitivity
A variety of range, maximum measuring 200m (Water column pressure)
Adopting the 316L stainless steel diaphragm, applicable to a variety of measuring medium
Flexible configuration, select different configuration according to requirements.
Reverse polarity and overvoltage protection
Shock and lightning protection design
Laser trimming resistance temperature compensation, zero and range can be adjusted on site
Anti-Corrosion, suitable for a variety of medium
Overload and strong anti-interference ability, stable performance
Application of China supplier level gauge :
Industrial site level measurement and control
City water supply and sewage treatment
hydrological monitoring of Petroleum, chemical industry, power plant industry
Level measurement and control of reservoirs, DAMS, water and electricity construction, etc
Technical Data of level gauge :
Measurement Range | 0-1-200m H2O |
Allowed overload | 2 times the full range pressure |
Working temperature | -20 to 80℃ |
Temperature compensation | -10 ~70℃ |
Storage Temperature | -40 to 80℃ |
Accuracy (Include nonlinearity, repeatability, hysteresis) | 0.2%FS(Typical), ±0.5%FS(Max) |
Stability error | 0.2%FS(Typical), ±0.5%FS(Max) |
Temperature drift coefficient | 0.01%FS(Typical, the range is not less than 5m H2O), 0.03%FS(Typical, the range is less than 5m H2O) |
Output signal | 4-20mA (2/3 wire), 0-10/20mA 0-5V, 1-5V, 0-10V |
Supply power | 15-36VDC (Standard 24VDC) |
Load (Ω) | Current output type<(U-15V)/0.02A, Current output type>5K |
Case Material | Aluminum alloy |
O-ring | Fluorine rubber |
Diaphragm | 316L stainless steel |
Cable | Special waterproof breathable cable, Ptfe anti-corrosion breathable cable |
Protection Grade | IP68(pressure sensor part), IP65(Junction box transmitter) |
Company Profile
Xian Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer, Mr Tian has more than 30 years experience on this area, and he is one of the engineers who introduced the Rosemount technology.
We are specialized in developing pressure transmitter, etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
