Specifications
latest hart communication equipment 475 hart communicator hart communicator 375good quality
low price
CE certificate
latest hart communication equipment 475 hart communicator hart communicator 375
Description of hart communication equipment:
hart communication equipmetn announces the next generation of handheld communicators.
The 475 Field Communicator delivers:
1.An innovative full-color graphical interface
2.Powerful diagnostics from devices in the field
3.A long-lasting Lithium-Ion power module for days – not hours – of battery life
4.Quick boot up and fast operating time
5.Universal support for HART, WirelessHART, and FOUNDATION fieldbus devices
6.ValveLink Mobile for powerful diagnostics on Fisher FIELDVUE digital valve controllers
7.Localized language versions of user interface in English, German, Russian, and Japanese .
8.Special notice for users upgrading their 475 Field Communicator to version 3.2 and higher software
PROCESSOR AND MEMORY SPECIFICATIONS of hart communicator 475:
80 MHz,max 133 MHz Hitachi SH3
Internal Flash : 32 MB
System Card: 1 GB Secure Digital card or higher
RAM: 32B
PHYSICAL SPECIFICATIONS of 475 hart communicator :
Weight: Approximately 1.65 lb (750 grams) includes battery
Display:3.5” diagonal, 1/4 VGA (240 by 320 pixels) color touch screen
Hard-coated surface
Dimensions approximately 2.79”×2.10”(71 mm × 53.3 mm)
Keypad:The keypad consists of the following:
A Power key to turn on and off the 475 or to put it in standby
A Backlight key to adjust the intensity of the light on the screen
Four navigation (arrow) keys to select, open, and back out of menu items
An Enter key to open menu items from the Field Communicator Main Menu or Settings menu,
and select any highlighted button
A Tab key to move between buttons or fields on a window
A Function key that enables alternate functionality indicated by the blue text neat the keys
Alphanumeric keys for entering data
USAGE SPECIFICATIONS of hart 475 communicator:
Temperature Limits: +14°F to +122°F (-10°C to+50°C)
0%to95% RH (non-condensing) for +32°F to +122°F(0°C o +50°)
Storage with Batteries: -4°F to 131°F(-20°C to +55°C) for less than 1 month
Storage without Batteries:-4°F to 140°F(-20°C to +60°C)
Enclosure Rating:IP51
Shock:Passes the 1-meter drop test onto concrete
General Guidelines: Only use new, original parts
Do not recharge the battery in hazardous areas
Have repairs done by only qualified personnel
Charge or power using only the Field Communicator power supply/charger
About Us:
Xi'an Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer Mr Tian has more than 30 years on this area, he is one of the engineers who introduced the Rosemount technology. We specializing in developing high precision pressure transmitter and pressure gauges. And we also develop temperature transmitter, level transmitter, densitometer etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
