Product Details
Place of Origin | Shaanxi, China | Brand Name | Yunyi | |
Model Number | XY-202 |
Intelligent Pressure Calibrator (header) Standard packing(or according to the customer request)
Product Description
Specifications
Intelligent Pressure Calibrator (header)1 professional manufacturer
2 cE
Intelligent Pressure Calibrator (header)
Description of Intelligent Pressure Calibrator (header) :
XY-202 intelligent pressure calibrator with HART protocol, with full-scale pressure measurement, high accuracy DC current, voltage measurement and 24VDC power output of the instrument. Can be used to verify the ordinary (precision) pressure gauges, pressure transmitters, pressure control valves, pressure switches and pressure measurements in real time, and can debug HART smart pressure transmitter.
Technical parameters of Intelligent Pressure Calibrator (header) :
function | range | index |
current | 25.0000 mA | accuracy±(0.02%RD+0.003%FS) |
voltage | 25.0000 V | accuracy±(0.02%RD+0.003%FS) |
swich | on/off | If the switch with checking voltage, voltage range (1~12)V |
output | range | index |
power output | DC24V±0.5V | max output 50mA, Overload protection current 120mA |
Power supply: internal batteries or special power adapter
Battery working time: about 100 hours, 24V when the load is reduced accordingly
Battery charge time: about 3 hours
Dimensions: 300mm * 200mm * 145mm
Weight: 4Kg
About Us:
Xi'an Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer Mr Tian has more than 30 years on this area, he is one of the engineers who introduced the Rosemount technology. We specializing in developing high precision pressure transmitter and pressure gauges. And we also develop temperature transmitter, level transmitter, densitometer etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
If you need this Intelligent Pressure Calibrator (header) , please visit the website
