Oil pressure sensor
Features:
| Core special ceramic body | ||||
| Low cost | ||||
| A rugged,compact design | ||||
| Wide working temperature:-20~125℃ | ||||
| Reverse voltage and overvoltage protection | ||||
Parameter:
Pressure range:0-5.0Mpa
Pressure mode:ventilation gage pressure or sealed gage pressure
Working voltage:5±0.5VDc
Output signal:0.5~4.5VDc(proportional output)
Loda resistance:10KΩ( typical)
Accuracy:±0.5%FS
Zero error :±0.5%FS
The total error:±1%FS
Compensation temperature:-20~85℃
Working temperature:-20~125℃
Storage temperature:-40~125℃
Overload capacity:3 times
Failure pressure:5 times
Life span:more than 9 million times pressure cycle
Long time stability:0.25%FS
Measurement of medium: Mediums compatible with 304L
Response time:less thatn 1mS
Shock resistance:50g,11mS
Vibration resistance:20g,10~2000Hz
Insulation resistance:more than 100MΩ@250VDc
Pressure interface:7/16-20UNF
Electric connections:Metri-Park 150 3pin or others
Protection grade:IP65
Weight: 80g
Drawing:
About Us:
Xi'an Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer Mr Tian has more than 30 years on this area, he is one of the engineers who introduced the Rosemount technology. We specializing in developing high precision pressure transmitter and pressure gauges. And we also develop temperature transmitter, level transmitter, densitometer etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
If you need oil pressure sensor , please visit the website
skype:wangxiaoyuncalar
