4 digit led control digital pressure transducer
Description :
Integral component of stainless steel, elastomer original imported
high-precision strain gauge and advanced technology, with high sensitivity,
stable performance, good impact resistance. 316 stainless steel welded closed,
the pressure sensor LED display comes with three and a half, while the output
analog signals to the back-end control mechanism to pressure signal sampling,
compact, compact, good moisture resistance and excellent media
compatibility.
Specification :
Range: -0.1 ~ 100 (MPa)
Comprehensive Accuracy: 0.25% FS, 0.5% FS, 1.0% FS
Output signal: 4 ~ 20mA (two wire), 0 ~ 5V, 1 ~ 5V, 0 ~ 10V (three-wire)
Site display: LED three half 0000 - 1999
Supply voltage: 24DCV (9 ~ 36DCV)
Medium temperature: -20 ~ 85 ~ 150 ℃
Ambient temperature: room temperature (-20 ~ 85 ℃)
Load Resistance: Current Output: Maximum 800Ω; Voltage output: more than
50KΩ
Insulation resistance: more than 2000MΩ (100VDC)
Sealing Rating: IP65
Long-term stability: 0.1% FS / Year
Vibration: Mechanical vibration frequency within 20Hz ~ 1000Hz, output
changes less than 0.1% FS
Electrical connection: Hirschmann connector
Threaded connection: M20 × 1.5, etc., other threads can be designed
according to customer requirements
Pressure transmitter
Package: standard export packing , including instructions and certificate
Shipment: Express (FedEx, DHL, UPS & TNT) or forwarder
Xi'an Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer Mr Tian has more than 30 years on this area, he is one of the engineers who introduced the Rosemount technology. We specializing in developing high precision pressure transmitter,pressure gauges,pressure calibrator and deadweight tester.And we also develop flow meter, level transmitter, densitometer etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other field...
If you need this Pressure Tranmitters with LED Display , please contact
Katherina Wang skype:wangxiaoyuncalar
Or visit website for more details
