CJPB ,CJPT 10*15D needle pneumatic cylinder , double action Needle cylinder
Features:
1) CJP series needle cylinder ,compact design minimizes mounting space .
2) Be available in two mounting types:panel mounting and embedding mounting.
3) Single action with spring return and double action are available.
4) Precision grinding piston rod,cylinder parts were processed by high precision CNC lathe and CNC machining centre,and also good seals to guarantee good action and long lifetime.
Specification:
Pneumatic cylinder Air cylinder CJP Series Needle Cylinder
CJP Series Pin Cylinder is single spring extend type cylinder. Compact design result in efficient space-saving installation. There are plating mounting and inside-hiding two fixing types. Male thread or no thread is optional at the rod end. 6mm, 10mm, 15mm is available as bore size. The stroke is from 5mm to 30mm.
Bore size |
6 |
10 |
15 |
working fluid |
Air |
||
Working type |
Single acting-spring in |
||
Max working pressure |
0.7 |
||
Min working pressure |
0.12 |
0.06 |
|
Ambient & fluid temperature |
Without sensor switch:-10℃,with sensor switch:-10℃~60℃ |
||
Cushion |
Rubber cushion in two ends |
||
Piston working speed |
50~500mm/s |
||
Stroke tolerance |
|
||
Oil supply |
No need |
||
Port size |
M5X0.8 |
||
Ordering code :
Dimension size:
Products:
In addition to our cooper parts mainly used in pneumaic and hydraulic fidlds , we have developed pu air tubes ,samll ball valves,quick couplings,ect.RIXIN BRASS FITTING CO.,LTD founded in 1991 . The factory is a private enterprise covering the complete process of design , manufacture,marketing and service.
Professional production equipment
The factory has five production line,more than 100 workers . Cutting workshop make the brass raw material into appropriate length.after cutting some material send to Instrument lathe workshop and CNC workshop ,some of material send to punch workshop processed into the shape which we need. our CNC work shop Produces the product accuracy can be controlled in the error of 0.01 mm . And punch workshop can make goods according to your needed . The Assembly shop with automated equipment , Reduce the error of the product. PU tube workshop using European automation equipment,and clean management.
Rich processing experience
Our engineers team with rich experience in production line, an average of more than 10 years of experience in practice
Each year more than a month of study and communication It is our claim to the engineer.we have the modern warehouse management to ensure that the appropriate inventory to guarantee the delivery time, through the information management to reduce the warehouse cost, make products with competitive price.
Profession design team
We have our own product design team, and packaging design team.Help us to make the products fit your market , and help you win the market. we can make your logo on products and make the packaging with your logo or your design .
Rigid quality control
Every products we produce with strict inspection more than two times before packaging. We have a full set of inspection equipment,to do Pressure test and temperature test,some of products will do the durability test.To ensure every products with good quality .
