Industrial water line chlorine analyzer flowmeter made in China
1.Outline
Industrial water line chlorine analyzer is a microprocessor-line monitor. Used in drinking water treatment plants, drinking water distribution network, swimming pools, industrial wastewater, cooling water circulation on the chlorine content in the water for continuous monitoring and control.
Meter with LCD display; intelligent Chinese menu operation; has a current output selectable measurement range set free, high and low limit alarm prompts and two relay control switch hysteresis range is adjustable; Automatic or manual temperature compensation; automatic or manual pH compensation; electrode variety of automatic calibration mode; RS485 / / RS232 communication and computer connections.
According to user needs to provide flow-through [] [] [Buried Pipeline installation process] and other forms of chlorine electrode.
2 .Structural characteristics and working principle
2.1 Structural features:
Major components of the entire measuring system consists of two parts, the instrument ( secondary instrument ) , chlorine electrode ( a table ) and so on. Chlorine electrode contact test solution, the meter displays the value of the aqueous solution of chlorine , pH and temperature values , and work status .
2.2 How it works:
By the signal measurement instrumentation , computing , display, network communications and command panels and other components . Temperature probe , pH electrode and the sample containing chlorine electrode signal is amplified by the instrument into operation into a low-impedance voltage signal display measured values.
Chlorine gold electrodes (Pu) as a cathode , silver (Ag) as the anode , the electrolyte was filled with 0.1M potassium chloride solution, i.e., (KCl), with selection using hypochlorous acid (HOCl) in the membrane , this membrane only hypochlorous acid molecules can freely penetrate , and hypochlorite ions (ClO-) and chlorine were not through . When measured between the anode and the cathode with the polarization voltage , HOCl molecules through the membrane at the cathode consumption, proportional to the concentration of hypochlorous acid is formed and a current flows through the electrodes , and this current is detected by the instrument into operation the concentration of hypochlorous acid while pH and temperature electrode test solution pH and temperature , chlorine content of the water meter converted in accordance with the detected pH and temperature.
3 .Technical Parameters
( 1 ) Measurement Range : chlorine ( can be set ): 0 ~ 20.00mg / L (ppm); temperature : 0 ~ 60 ℃;
( 2 ) Resolution: Chlorine : 0.001mg / L; Temperature : 0.1 ℃;
( 3 ) Automatic or manual temperature compensation range : 0 ~ 60 ℃ ( reference temperature 25 ℃)
(4) pH compensation range : Manual pH compensation : 5 ~ 9pH;
( 5 ) Response time : <2min (90%, 20 ℃)
( 6 ) the minimum flow circulation installation : 15cm3 / S ( to maintain a constant flow rate )
( 7 ) Stability : at room temperature , per month drift <2% F • S
( 8 ) isolated signal output : 0 ~ 10mA ( load resistance <1.5KΩ); 4 ~ 20mA ( load resistance <750Ω);
( 9 ) two relay control contact : 3A 240VAC, 6A 28VDC or 120VAC;
( 10 ) Power supply : 220VAC ± 10%, 50 ± 1Hz, power ≤ 3W;
24VDC, power ≤ 1W ( reservation required ); 12VDC, power ≤ 1W ( reservation required ) ;
( 11 ) Dimensions : 96 × 96 × 130mm;
( 12 ) Installation: panel mounting ( embedded ) ; Opening : 91 × 91mm;
( 13 ) Wall-mounted : Waterproof Wall Box Size: 300 (H ) * 200 ( W ) * 167 (D ) mm;
( 14 ) Instrument Weight : 0.6kg;
( 15 ) Working environment:
Ambient temperature : -10 ~ 60 ℃;
Relative humidity: less than 90% ;
In addition to the Earth's magnetic field without strong magnetic field around it.
4 Features
1)Intelligence: the use of chip microprocessor completed chlorine value, pH value measurement, temperature measurement;
2)Man-machine dialogue: menu operation structure, follow the prompts on the screen the user can operate;
3)Multi-parameter with the screen display: Simultaneous display of chlorine value, pH, temperature and working conditions;
4)Software set the output mode: software selection 0 ~ 10mA or 4 ~ 20mA output;
5)Measuring ranges and alarm, lower limit set free; upper and lower limit alarm alerts;
6)Two relay control switch, adjustable hysteresis control range;
7)Since password: Users can set up or change the password to avoid unauthorized personnel into the lead to misuse;
8)RS485 / / RS232 communication interface connected to the computer.
