electronic chlorine tester
Description of electronic chlorine tester :
residual chlorine analyzer is a microprocessor-controlled instrument. The instrument is widely used in drinking water treatment plants, drinking water distribution network, a swimming pool, water treatment works, sewage treatment, water disinfection (chlorine dioxide generator package) and other process industries, aqueous solution of chlorine and temperature values continuous monitoring and control.
Technical Parameters of electronic chlorine tester :
( 1 ) Measurement range ( can be set manually ) :
I chloride : 0 ~ 2.00mg / L (ppm);
0 ~ 5.00mg / L;
0 ~ 10.00mg / L;
0 ~ 20.00mg / L;
Temperature : -5 ~ 60.0 °C;
( 2 ) Resolution:
I Chlorine : 0.001mg / L; Temperature : 0.1 °C;
( 3 ) Basic error :
I Chlorine : ± 1% F • S; temperature : ± 0.3 °C;
( 4 ) Response time : 90% less than 90 seconds ;
( 5 ) pH compensation range : Manual pH compensation : 5 ~ 9pH;
( 6 ) isolated current output:
0 ~ 10mA ( load resistance <1.5KΩ);
4 ~ 20mA ( load resistance <750Ω);
( 7 ) two relay control contact : 3A 240VAC, 6A28VDC or 120VAC;
( 8 ) Instrument Power Supply:
220VAC ± 10%, 50 ± 1Hz, power ≤ 3W;
24VDC, Power : ≤ 1W ( optional ) ;
12VDC, Power : ≤ 1W ( optional ) ;
( 9 ) Instrument Dimensions : 96 × 96 × 130mm;
( 10 ) Meter Installation: panel mounting ( embedded ) ;
Installation hole size : 91 × 91mm;
Wall-mounted : 300 × 200 × 167mm;
( 11 ) Optional features:
RS485 / / RS232 communication interface connected to the computer ;
( 12 ) Instrument Weight : 0.6kg;
( 13 ) Instrument working environment:
Ambient temperature : -10 ~ 60 °C;
Relative humidity: less than 90% ;
In addition to the Earth's magnetic field without strong magnetic field around it. dust
Features of electronic chlorine tester :
LCD large-screen LCD
Chinese intelligent menu operation
A variety of automatic calibration function
Optional signal output
Manual, automatic temperature compensation
Manual pH value compensation
Two relay control switch
High limit and low limit, hysteresis control
RS485 / / RS232 communication connection optional
Same interface displays chlorine, PH and temperature values
Password protection is provided to prevent the misuse of non-staff steel
