Digital Display Vickers Hardness Tester

Digital Display Vickers Hardness Tester photo-1
US$ 50 - 100 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Shaanxi, China
Brand Name:
Yunyi
Model Number:
W-20
Payment & Shipping
Payment Methods:
Port of Shipment:
beijing shanghai tianjin shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shaanxi, China
Brand Name Yunyi
Model Number W-20
Power Other
Usage Hardness Tester

Digital display Vickers hardness tester

Features of digital display Vickers hardness tester  :





1.  Mainly is suitable for the measurement of tiny, thin shape, surface infiltration coating                  specimen vickers hardness and determination of glass, ceramics, agate, brittle and hard              material such as artificial gem knoop hardness.

2.  Instrument on the mechanical, optical, light source adopts unique design of precision make          the indentation image clearer, more accurate measurement

3.  Equipped with 10 times and 20 times the objective lens, 20 times for measuring, 10 times for      viewing instrument. Adopts digital display micrometer eyepiece, no table, no input values,          measurement data directly displayed on the screen, and display the test force, prompt                information of the load time and frequency, etc.

4.  Instrument on the light source adopts cold light source, instrument life 100000 hours.
5.  Imported LCD screen LCD display and menu type structure, transformation of HV/HK              scale, hardness value transformation, the test result is obtained by internal data processing,          and display on the LCD screen
6.  A special interface instrument or optional CCD automatic measuring system LCD video              measurement system.



Technical parameters of digital display Vickers hardness tester  :



1.  The test force 2.94 N (0.3 Kgf), 4.9 N (0.5 Kgf), 9.80 N, 19.6 Kgf (1) N (2.0 Kgf), 29.4 N         (3.0 Kgf), 49.0 N (5.0 Kgf)

2.  The range of hardness testing: 8 hv0.1. 3 ~ 2900 hv5

3.  The test force exerting methods: automatic unloading test force

4.  The measuring microscope magnification: 100 x

5.  Lift the load time test: 0 ~ 60 s (for a unit per second, any type)

6.  Minimum detectable units: 0.0625 microns

7.  Specimen maximum height: 160 mm

8.  The pressure head center to the outer wall distance: 135 mm

9.  The host weight: about 40 kg

10. Power supply: AC220V / 50 hz

11. Installation dimensions (length x width x height) (520 * 190 * 190) mm

digital display Vickers hardness testerdigital display Vickers hardness tester


digital display Vickers hardness testerdigital display Vickers hardness tester
