Specifications
data acquisition system rs485 digital pressure gauge1 professional manufacturer
2 quick shipment
Data acquisition system rs485 digital pressure gauge
Technical parameters data acquisition system rs485 digital pressure gauge :
1 Measuring range: gauge:-100kPa ~ 0 ~ 1kPa ~ 260MPa
Differential pressure: 0 ~ 500Pa ~ 3.5MPa Absolute pressure: 0 ~ 10kPa ~ 60MPa
2. Communication: RS485 (MODBUS RTU protocol)
3. Accuracy class: 0.1, 0.2, 0.5
4. Stability: better than 0.1% FS / year better than 0.2% FS / Year
5. Display: LCD digital display dynamic four (equivalent to four and a half) plus Han
Word prompts, you can display kPa, MPa pressure units etc.
6. Overload pressure: 1.5-3 times the range, depending on the measurement range may be
7. Communications Power: 7 ~ 30VDC external power supply
8. Medium temperature: -40 ~ 85 °C
9. Working environment: Temperature: -30 °C ~ 60 °C; Humidity: <90%
10. Explosion levels: ExiaIIBT4, ExdIIBT4
11. Electrical connection: M20 × 1.5 (female)
12. Process connection: M20 × 1.5 (male) or according to user requirements
Features of data acquisition system rs485 digital pressure gauge :
1 Long life, high accuracy, long-term stability
2 Advanced power management technology
3 Unique RFI technology, a perfect match for digital radio remote monitoring
4 Support RS485 communication, never dropped communications technology, bus supports 255 devices
5 Enhanced lightning technology to ensure the security instrument
6 White backlight, clear display
7 Zero self-stabilization technology
8 vTemperature compensation
About Us:
Xi'an Yunyi Instrument Co., Ltd. is a professional manufacturer that engaged in the fields of pressure measurement instrument, the chief engineer Mr Tian has more than 30 years on this area, he is one of the engineers who introduced the Rosemount technology. We specializing in developing high precision pressure transmitter and pressure gauges. And we also develop temperature transmitter, level transmitter, densitometer etc. They are widely used in chemical, petroleum, paper, electricity, city gas, environmental protection, water treatment and other fields.
If you need this data acquisition system rs485 digital pressure gauge , please visit the website
or contact skype:wangxiaoyuncalar
