Disinctive Design Laboratorial Single Channel SyringePump LSP01-1A

Disinctive Design Laboratorial Single Channel SyringePump LSP01-1A thumbnail-1
Disinctive Design Laboratorial Single Channel SyringePump LSP01-1A photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
Longer
Model Number:
LSP01-1A
Contact Supplier Request Quote Chat Now
Beijing Mingbofei Science Technology Limited Company
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin & Shanghai & Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hebei, China
Brand Name Longer
Model Number LSP01-1A
Theory Other, Syringe Pump
Structure Other, Laboratorial Syringe Pump
Usage Other, Laboratorial Syringe Pump
Application Other, Laboratorial Syringe Pump
Power Other, AC 100 - 240 V

Disinctive Design Laboratorial Single Channel SyringePump LSP01-1A



Product Description

LSP01-1A & LSP01-2A  laboratorial syringe pumps are single channel syringe pump which only has infusion mode. The acceptable syringe specification is from 10 μL to 60 mL. Suitable for high accuracy and small flow rate liquid transferring.


   Disinctive Design Laboratorial Single Channel SyringePump LSP01-1A









Specifications:



Syringe pump LSP01-1A LSP01-2A
No. of Syringes 1 1
Advance per Mircostep 1/16step: 0.156 μm 1/16step: 0.031 μm
Infusion Volumn per Microstep 0.13 μL (60 mL BD Syringe) 0.026 μL (60 mL BD Syringe)
Syringe Size 10 μL - 60 mL 10 μL - 60 mL
Max. Linear Rate 65 mm/min 13 mm/min
Min. Linear Rate 5μm/min 1μm/min
Flow Rate  0.831 nL/min -  54.155 ml/min 0.166 nL/min -  10.83 ml/min
Working Mode     Infusion
Linear Force > 9 kgf
Max. Step Rate 6933  (1/16step)/ sec
Min. Step Rate 16  (1/16 step) /30 sec
Accuracy ≤ 0.5% error in the condition of > 30% of max. infusion distance
Setting Mode Rotary coded switch and membrane keypad
Display 128 x 64 graphic LCD
Power AC 100 - 240 V
Operating Condition Temperature  5 °C - 40 °C       Relative humidity < 80 %
Dimensions 280 × 210 × 140 mm 280 × 210 × 140 mm
Weights 3.6 kg 3.6kg











Parameters:



Type Product Code Syringe Syringe ID (mm) Flow Rate (μl/min-ml/min)
LSP01-1A 0503401 10μl 0.50 0.001-0.0128
25μl 0.80 0.0025-0.0327
50μl 1.10 0.0048-0.0618
100μl 1.60 0.0101-0.1307
250μl 2.30 0.0208-0.2701
500μl 3.25 0.0415-0.5392
1ml 4.72 0.0875-1.1373
2ml 9.00 0.3181-4.1351
5ml 13.10 0.6739-8.7608
10ml 16.60 1.0821-14.068
20ml 19.00 1.4176-18.429
30ml 23.00 2.0774-27.006
60ml 29.14 3.3346-43.349









 Feasures:



  • Syringe Selection: The syringe can be selected in the manufacturer table which includes manufacturer, material and size or input the inner diameter of the syringe barrel directly.
  • Easy to operate: Combining big screen LCD display with rotary coded switch and membrane keypad makes the operation simple and prompt.
  • Working Mode: Infusion
  • Memory Function:

1. The parameters are saved in EEPROM. The parameters don't need to be reset when power returns after an interruption.

2. In flow rate mode, the pump remains running or stop according to the setting parameters when power returns after an interruption.



  • Protection Function: The pump will stall and give an alarm when the drive structure of the pump is blocked.
  • Communication Function: Realize computer control through RS485 communication interface.
  • External Control Function: Input/output control.
  • Calibration Function: Acquire accurate volume through calibration.
  • Syringe Protection: Adjust syringe rest to prevent syringe from damaging.
