Electronic tensile strength test /universal testing machine/ tensile tester

Electronic tensile strength test  /universal testing machine/ tensile tester

Equipment overview:

EMT2000-B series liquid crystal electronic tensile testing machine is a new type of material testing machine with electronic technology and mechanical transmission. It has a wide range of loading speed and measuring range. It has high accuracy and sensitivity for measuring and controlling load and displacement.

EMT series precision is 1%, with the operation simple and convenient, especially suitable for the production line to control the quality of the testing instrument. The series models are mainly used in the test load of non metallic materials, which is less than 5kN.

Main function:

Test of tensile, peeling, tearing, and special test of a variety of non metallic materials.

Main features:

1: uses high-speed DSP platform, its high integration, powerful control, data processing capability, high reliability, is the use of other processors can not match the test machine.

USB1.1 2: communication, communication rate is 12Mb/s, the use of full speed mode, bulk transfer mode.

3: system board uses 4 layers of PCB unique anti interference routing method, strong anti-interference ability.

4: in addition to the power interface, the other interfaces are using the standard USB interface, plug and play interface such interface can be realized hot swap, that is, plug and play function. Interface features can be set up by software online. The interface neat layout reasonable, convenient plug.

5: the whole control system has a very high cost, high reliability.

6: have the perfect protection, overload protection, emergency stop and other safety protection function.

Meet standards:

"Electronic universal testing machine 16491-1996 GB/T"

Application industry:

Measurement of quality control, rubber, electronic, electrical, automotive, textile, chemical fiber, wire and cable, packaging materials and food, instrument and meter, medical instruments, civil nuclear energy, civil aviation, civil aviation, scientific research institute, commodity inspection, technical supervision departments, building materials ceramics, petrochemical, other industries.

Original configuration:

Drawing jig 1 set

Scalable configuration:

According to the test standard or test sample provided by the customer or the test sample of the fixture or special design of the fixture and accessories, the cost of the other.

Technical parameters:
