Home > Instruments & Meters > Test Instrument > Test Machine > Automatic Constant Speed JCH-3 Winch Controller

Automatic Constant Speed JCH-3 Winch Controller

Automatic Constant Speed JCH-3 Winch Controller photo-1

Automatic Constant Speed JCH-3 Winch Controller photo-2

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Chongqing, China

Brand Name:

Model Number:

JCH-3

Contact Supplier Request Quote Chat Now

Shandong Banner International Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Chongqing, China

Brand Name BN

Model Number JCH-3

Power Electronic

Usage Auto Testing Machine

Automatic constant speed JCH-3 Winch Controller

JCH-3 Winch Controller

l Main features

l Advanced AC variable-frequencyregulating speed technology

l Automatic constant speed and manual speed control, automatic overload protection

l Automatically calculate the depth, self-compensate depth error

l Self-locking function while winch ascending and descending

l Steady in velocity without jitter in full speed range

Main Technical Specifications

Velocity Range	1~30m/min
Constant Velocity Range	0.5~20m/min, error ±10%
Depth Range	0~9999.99 meter, Error ≤±0.4‰
Power Supply	AC220V±10% 50Hz ±5%
Continuous working time	≤24 hours
Deep Plus Equivalent	0.25mm/plus
Working Temperature	-10℃~ +70℃
Volume	305200220mm
Weight	<3kg

Winch series

Index/Name	3000m Frequency conversion winch	2000m Frequency conversion winch	1000m Frequency conversion winch	500m manually winch	300m
Type	JCH-3000	JCH-2000	JCH-1000	JCW-500	JCS-300
Dimension(mm)	940800720	920680700	710620670	540400380	560490360
Weight(net)	150kg	120kg	110kg	18kg	25kg
Motor Power	2.2kw	1.5kw	1.1kw	manually	manually
Encoder Plus	4000/ round	4000/ round	4000/ round		4000/round
Round Length(m) (diameter4.65mm)	3100	2200	1200	700	360
Round Length(m) (diameter4.65mm)	3100	2200	1200	370(Φ7 rubber cable)	360
Collecting ring	6 cores	6 cores	6 cores	6 cores	6 cores
